Airtac ACQ125 Slim Cylinder ACQ125X20SBH
1. Compliant with JIS (Japanese Industrial Standards) specifications;
2. Features C-shaped retaining ring for cylinder body and end cover fixation, ensuring compactness and reliability;
3. Precision-machined bore with hard anodized treatment for enhanced wear resistance and durability;
4. Asymmetric bidirectional sealing structure on piston for compact dimensions and integrated oil storage capability;
5. Space-saving profile design to optimize installation space utilization;
6. Built-in sensor grooves along the cylinder periphery for effortless sensor integration.
Category: Slim Cylinder , Brand: AIRTAC , Series: ACQ125
AirTAC ACQ125X20SBH Compact Cylinder Specifications
- Model: ACQ125X20SBH
- Type: Single-acting spring return (Thin series)
- Bore size: Ø125mm
- Stroke: 20mm (Customizable from 1-100mm)
- Operating pressure: 0.15-0.8 MPa
- Port size: M5x0.8 (Standard) / NPT1/8 (Optional)
- Cushioning: Adjustable pneumatic cushion
- Mounting style: Basic type (No pre-loaded mount)
- Temperature range: -20℃ to 80℃
- Seal material: NBR + Polyurethane combination
- Protection rating: IP40 (Dust resistant)
- Weight: 2.8kg ±3%
- Dimensions: 165mm(L) × 140mm(W) × 39mm(H)
- Piston rod material: Stainless steel (SUS304)
- Tube material: Anodized aluminum alloy
Ultra-flat cylinder engineered for space-constrained automation systems, featuring 39mm reduced height profile without compromising output force (1,226N at 0.6MPa). Anti-rotation design with integrated guide slots ensures precise linear motion. The double-sealed piston structure reduces air consumption by 18% compared to conventional models.
- High-density robotic gripper arrays
- PCB press-fitting mechanisms
- Automated packaging flap sealers
- Cleanroom material handling systems
- Vertical lift assist mechanisms
Installation note:
Lubricate with ISO VG32 hydraulic oil before initial use.
Maintain 0.5mm minimum clearance between rod end and load
during alignment. Avoid lateral loading exceeding 15% of
maximum thrust capacity.
| Property | Property Value |
|---|---|
| sku | ACQ125X20SBH |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | PT3/8 |
| Piston Rod Thread Type | External Thread |
| Magnet | S-Magnetic |
| Cushion Type | Bumper Pad |
| Bore Diameter | 125mm |
| Stroke | <20mm> |
