Airtac ACQ125 Slim Cylinder ACQ125X250SB
1. Compliant with JIS (Japanese Industrial Standards) specifications;
2. Features C-shaped retaining ring for cylinder body and end cover fixation, ensuring compactness and reliability;
3. Precision-machined bore with hard anodized treatment for enhanced wear resistance and durability;
4. Asymmetric bidirectional sealing structure on piston for compact dimensions and integrated oil storage capability;
5. Space-saving profile design to optimize installation space utilization;
6. Built-in sensor grooves along the cylinder periphery for effortless sensor integration.
Category: Slim Cylinder , Brand: AIRTAC , Series: ACQ125
AirTAC ACQ125X250SB Thin-Type Cylinder Specifications
- Model: ACQ125X250SB
- Bore size: 125mm
- Stroke: 250mm
- Operating pressure: 0.05–1.0 MPa
- Cushion type: Fixed rubber buffer + adjustable cushion (both ends)
- Mounting style: Basic type (MF1) with foot mounting holes
- Port size: Rc1/4 (G1/4 optional)
- Piston speed: 50–800 mm/s
- Ambient temperature: -20℃ to 80℃
- Material: Aluminum alloy barrel, CRCA steel piston rod
- Seal type: NBR (standard), optional Fluorocarbon (FKM)
- Weight: 6.8 kg (dry, without accessories)
- Dimensions: 345mm(L) × 140mm(W) × 140mm(H)
- Rod thread: M20×1.5 (external)
- Max thrust: 1227N @ 0.63MPa
- Protection: IP54 (standard), IP67 optional
A space-saving pneumatic actuator with 40% reduced height compared to standard cylinders. Features dual-cushion design for smooth end-stroke deceleration and corrosion-resistant hard anodized piston rod. Compatible with auto switches (e.g., SME/SMT series) via T-slot mounting. Requires ISO 8573-1:2010 Class 3-4-3 compressed air.
- High-speed press machinery ejection systems
- Automated palletizing robot end-effectors
- Plastic injection molding machine core-pulling
- Lithium battery production line positioning
- Automotive welding fixture clamping
Installation note:
Maintain 0.5mm minimum lateral clearance during alignment. Lubricate with ISO VG32 hydraulic oil
during initial setup. For vertical mounting, use auxiliary rod support brackets (AVI series).
| Property | Property Value |
|---|---|
| sku | ACQ125X250SB |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | PT3/8 |
| Piston Rod Thread Type | External Thread |
| Magnet | S-Magnetic |
| Cushion Type | Bumper Pad |
| Bore Diameter | 125mm |
| Stroke | <250MM> → <250mm> |
