Airtac ACQ125 Slim Cylinder ACQ125X300SB
1. Compliant with JIS (Japanese Industrial Standards) specifications;
2. Features C-shaped retaining ring for cylinder body and end cover fixation, ensuring compactness and reliability;
3. Precision-machined bore with hard anodized treatment for enhanced wear resistance and durability;
4. Asymmetric bidirectional sealing structure on piston for compact dimensions and integrated oil storage capability;
5. Space-saving profile design to optimize installation space utilization;
6. Built-in sensor grooves along the cylinder periphery for effortless sensor integration.
Category: Slim Cylinder , Brand: AIRTAC , Series: ACQ125
AirTAC ACQ125X300SB Compact Cylinder Specifications
- Model: ACQ125X300SB
- Series: ACQ Ultra-Slim Series
- Bore size: Ø125mm
- Stroke: 300mm (±0.5mm tolerance)
- Operating pressure: 0.1-0.9 MPa
- Operating temperature: -20℃ to 80℃
- Cushioning type: Adjustable buffer (both ends)
- Port size: 1/4" NPT (G1/4 optional)
- Mounting style: Double stud mounting (ISO 15552 compatible)
- Material: Aluminum alloy barrel, chromium-plated piston rod
- Seal material: NBR + Polyurethane hybrid seals
- Weight: 5.8kg (without accessories)
- Dimensions: 456mm(L) × 135mm(W) × 135mm(H)
- Piston rod thread: M20×1.5
- Max theoretical force: 1,227N @0.63MPa
- Speed range: 50-750mm/s
- ISO standard: 15552 (formerly ISO 6431)
Ultra-flat cylinder optimized for space-constrained installations, featuring 25% reduced cross-section compared to standard ISO cylinders. Precision-ground inner bore ensures ≤0.05mm ovality for consistent performance. The SB variant includes dual anti-rotation pins and reinforced end caps for lateral load resistance. Requires ISO VG32 or equivalent hydraulic oil lubrication.
- High-speed packaging line pusher mechanisms
- Plastic injection molding ejector systems
- Automated warehouse vertical lift gates
- Semiconductor wafer handling robots
- Press tooling alignment systems
Installation guidelines:
Maintain ≤0.1mm/m alignment tolerance during mounting. For vertical installations,
use counterbalance valves when handling suspended loads. Lubricate through air line
using 1-3 drops of oil per cycle via built-in lubricator ports.
| Property | Property Value |
|---|---|
| sku | ACQ125X300SB |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | PT3/8 |
| Piston Rod Thread Type | External Thread |
| Magnet | S-Magnetic |
| Cushion Type | Bumper Pad |
| Bore Diameter | 125mm |
| Stroke | 300mm |
