Airtac ACQ125 Slim Cylinder ACQ125X30SBH
$217.71
Regular price
$225.21
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
ACQ125X30SBH
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
ACQ125 Slim Cylinder
1. Compliant with JIS (Japanese Industrial Standards) specifications;
2. Features C-shaped retaining ring for cylinder body and end cover fixation, ensuring compactness and reliability;
3. Precision-machined bore with hard anodized treatment for enhanced wear resistance and durability;
4. Asymmetric bidirectional sealing structure on piston for compact dimensions and integrated oil storage capability;
5. Space-saving profile design to optimize installation space utilization;
6. Built-in sensor grooves along the cylinder periphery for effortless sensor integration.
Category: Slim Cylinder , Brand: AIRTAC , Series: ACQ125
Installation tip:
Ensure lateral clearance ≥5mm for magnetic sensor cables. Use locknuts (not included)
for vibration-prone applications. Lubricate rod with ISO VG32 hydraulic oil if used
in vertical downward orientation.
1. Compliant with JIS (Japanese Industrial Standards) specifications;
2. Features C-shaped retaining ring for cylinder body and end cover fixation, ensuring compactness and reliability;
3. Precision-machined bore with hard anodized treatment for enhanced wear resistance and durability;
4. Asymmetric bidirectional sealing structure on piston for compact dimensions and integrated oil storage capability;
5. Space-saving profile design to optimize installation space utilization;
6. Built-in sensor grooves along the cylinder periphery for effortless sensor integration.
Category: Slim Cylinder , Brand: AIRTAC , Series: ACQ125
AirTAC ACQ125X30SBH Compact Cylinder Specifications
- Model: ACQ125X30SBH
- Type: Double-acting thin cylinder with magnetic piston
- Bore size: 125mm
- Stroke: 30mm
- Operating pressure: 0.1–0.9 MPa
- Cushioning: Adjustable pneumatic cushion (both ends)
- Port size: G3/8 (M14 fine thread optional)
- Piston speed: 50–800 mm/s
- Ambient temperature: -20℃ to 80℃
- Seal material: NBR (Nitrile rubber)
- Mounting type: Basic type (axial foot mounting holes)
- Repeat accuracy: ±0.5mm
- Weight: 3.2 kg (excluding accessories)
- Dimensions: 203mm(L) × 125mm(W) × 62mm(H)
- Rod thread: M16×1.5
- Protection rating: IP54 (standard)
Ultra-flat profile cylinder (height ≤1/3 of conventional models) optimized for space-constrained automation systems. Features integrated magnet for position sensing and reinforced aluminum alloy end caps. Pre-lubricated for maintenance-free operation up to 2,000 km travel distance.
Typical Applications:
- PCB handling robots in electronics assembly
- Clamping mechanisms in CNC rotary tables
- Vertical lift systems in cleanroom environments
- Packaging machine pusher arms
- Medical device positioning stages
Installation tip:
Ensure lateral clearance ≥5mm for magnetic sensor cables. Use locknuts (not included)
for vibration-prone applications. Lubricate rod with ISO VG32 hydraulic oil if used
in vertical downward orientation.
| Property | Property Value |
|---|---|
| sku | ACQ125X30SBH |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | PT3/8 |
| Piston Rod Thread Type | External Thread |
| Magnet | S-Magnetic |
| Cushion Type | Bumper Pad |
| Bore Diameter | 125mm |
| Stroke | 30mm |
