Airtac ACQ125 Slim Cylinder ACQ125X40S
1. Compliant with JIS (Japanese Industrial Standards) specifications;
2. Features C-shaped retaining ring for cylinder body and end cover fixation, ensuring compactness and reliability;
3. Precision-machined bore with hard anodized treatment for enhanced wear resistance and durability;
4. Asymmetric bidirectional sealing structure on piston for compact dimensions and integrated oil storage capability;
5. Space-saving profile design to optimize installation space utilization;
6. Built-in sensor grooves along the cylinder periphery for effortless sensor integration.
Category: Slim Cylinder , Brand: AIRTAC , Series: ACQ125
AirTAC ACQ125X40S Thin Cylinder Specifications
- Model: ACQ125X40S
- Type: Compact ISO 6432 compliant double-acting cylinder
- Bore size: Ø125 mm
- Stroke: 40 mm (standard) | Customizable up to 300 mm
- Operating pressure: 0.05–1.0 MPa
- Operating temperature: -20℃ to 80℃
- Cushioning: Adjustable rubber buffer + shock absorber
- Mounting style: Basic front flange (MF1) | Optional foot mounts
- Port size: G1/2 (NPT1/2 optional)
- Piston rod material: Hard chrome-plated steel
- Tube material: Anodized aluminum alloy
- Seal type: NBR seals (FKM available for high-temp)
- Built-in magnet: Yes (for magnetic sensor compatibility)
- Weight: 4.7 kg ±2% (without accessories)
- Dimensions: 198mm(L) × 144mm(W) × 144mm(H)
- Max theoretical force: 1,227N @ 0.63MPa
- Protection rating: IP67 (dust/water resistant)
Ultra-flat cylinder engineered for high-force applications in space-constrained environments. Features dual anti-rotation guide rods for enhanced lateral stability during vertical operations. Precision honed tube ensures ≤0.05mm ovality for consistent performance. Pre-lubricated for maintenance-free operation up to 3,000km service life.
- Press brake tooling positioning systems
- Automotive welding fixture clamping
- Plastic injection mold core-pulling mechanisms
- High-cycle packaging machine actuators
- Semiconductor wafer handling robots
Installation tip:
Maintain 0.5-1mm alignment tolerance during mounting. Use flexible couplings
when connecting to guided slides. Lubricate rod end weekly in high-particulate environments.
| Property | Property Value |
|---|---|
| sku | ACQ125X40S |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | PT3/8 |
| Piston Rod Thread Type | Internal Thread |
| Magnet | S-Magnetic |
| Cushion Type | Bumper Pad |
| Bore Diameter | 125mm |
| Stroke | <40mm> |
