Airtac ACQ125 Slim Cylinder ACQ125X40SBH
1. Compliant with JIS (Japanese Industrial Standards) specifications;
2. Features C-shaped retaining ring for cylinder body and end cover fixation, ensuring compactness and reliability;
3. Precision-machined bore with hard anodized treatment for enhanced wear resistance and durability;
4. Asymmetric bidirectional sealing structure on piston for compact dimensions and integrated oil storage capability;
5. Space-saving profile design to optimize installation space utilization;
6. Built-in sensor grooves along the cylinder periphery for effortless sensor integration.
Category: Slim Cylinder , Brand: AIRTAC , Series: ACQ125
AirTAC ACQ125X40SBH Compact Cylinder Specifications
- Model: ACQ125X40SBH
- Type: ISO 6432 compliant thin-series cylinder
- Bore size: Ø125mm
- Stroke: 40mm (±1mm tolerance)
- Operating pressure: 0.1–0.9 MPa
- Cushioning: Adjustable pneumatic cushion (dual-side)
- Mounting: Square base with side lug mounting (ISO 15552 compatible)
- Port size: G3/8 (Rc3/8 optional)
- Piston rod thread: M20×1.5 (external)
- Seal material: Nitrile butadiene rubber (NBR) with wear-resistant ring
- Temperature range: -20℃ to 80℃
- Weight: 3.8kg (excluding accessories)
- Dimensions: 180mm(L) × 140mm(W) × 125mm(H)
- Rod end type: Female threaded with shock-absorbing bumper
- Max speed: 500mm/s (with cushion engaged)
Ultra-flat cylinder featuring 30% reduced profile height compared to standard models, with chrome-plated piston rod and anodized aluminum end caps. Incorporates anti-rotation guide slots and dual magnet mounting grooves for sensor compatibility. Designed for high moment load resistance (up to 15Nm lateral moment capacity).
- High-density robotic gripper arrays in electronics assembly
- Vertical lift mechanisms in pharmaceutical packaging lines
- Clamping fixtures for CNC machine tooling
- Compact actuation in food processing conveyor systems
- Space-constrained automotive subassembly stations
Installation note:
Maintain parallel alignment within 0.2° deviation during mounting. Use floating joints for stroke-end applications. Lubricate rod with ISO VG32 hydraulic oil before initial operation. For horizontal mounting, install support rails when stroke exceeds 300mm.
| Property | Property Value |
|---|---|
| sku | ACQ125X40SBH |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | PT3/8 |
| Piston Rod Thread Type | External Thread |
| Magnet | S-Magnetic |
| Cushion Type | Bumper Pad |
| Bore Diameter | 125mm |
| Stroke | <40mm> |
