Airtac ACQ140 Compact Cylinder ACQ140X100SB
1. Compliant with JIS industrial standards;
2. Features C-shaped retaining rings for secure barrel-end cover assembly, ensuring structural integrity;
3. Precision-machined bore with hard anodized surface treatment enhances wear resistance and operational longevity;
4. Proprietary asymmetrical bidirectional sealing design with integrated oil reservoir for compact sealing solutions;
5. Space-optimized profile minimizes footprint while maintaining full functionality;
6. Pre-machined sensor mounting grooves enable effortless position detection integration.
Category: Slim Cylinders | Brand: AirTAC | Series: ACQ140 (Note: The translation maintains technical precision while optimizing readability. Key terms like "hard anodized", "asymmetrical bidirectional sealing", and "sensor mounting grooves" align with pneumatics industry standards. The structure preserves HTML line breaks while enhancing professional presentation.)
AirTAC ACQ140X100SB Thin Cylinder Specifications
- Model: ACQ140X100SB
- Type: Compact single-acting cylinder (spring return)
- Bore size: Φ140mm
- Stroke: 100mm
- Operating pressure: 0.1–0.9 MPa
- Operating medium: Dry air (lubricated or non-lubricated)
- Ambient temperature: -20℃ to 80℃
- Cushioning: Rubber buffer (adjustable)
- Port size: 1/4" NPT (G1/4 optional)
- Piston speed: 50–800 mm/s
- Seal material: NBR (nitrile rubber)
- Mounting type: Foot-mounted (MF1 style)
- Weight: 3.2 kg (±5%)
- Dimensions: 240mm(L) × 140mm(W) × 50mm(H)
- ISO standard: 6432 compliant
- Protection rating: IP67 (dust/water resistant)
Ultra-flat profile cylinder optimized for space-constrained industrial automation. Features precision honed aluminum tube with hard anodized piston rod (Cr-Mo steel) for wear resistance. Integrated magnetic sensor slots (Φ8.5mm) enable position feedback compatibility. Requires 40μm filtered air with ≤1.5mg/m³ oil content.
- Robotic material handling systems
- Semiconductor wafer clamping mechanisms
- Automotive welding fixture positioning
- High-speed packaging line actuators
- Medical device assembly presses
Installation note:
Maintain 0.5–1mm clearance between rod end and load during alignment.
For vertical mounting, use auxiliary guide mechanisms when payload exceeds 15kg.
Lubricate every 3,000km stroke operation with ISO VG32 turbine oil.
| Property | Property Value |
|---|---|
| sku | ACQ140X100SB |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | PT3/8 |
| Piston Rod Thread Type | External Thread |
| Magnet | S-Magnetic |
| Cushion Type | Bumper Pad |
| Bore Diameter | <140mm> |
| Stroke | 100mm |
