Airtac ACQ140 Compact Cylinder ACQ140X300SB
1. Compliant with JIS industrial standards;
2. Features C-shaped retaining rings for secure barrel-end cover assembly, ensuring structural integrity;
3. Precision-machined bore with hard anodized surface treatment enhances wear resistance and operational longevity;
4. Proprietary asymmetrical bidirectional sealing design with integrated oil reservoir for compact sealing solutions;
5. Space-optimized profile minimizes footprint while maintaining full functionality;
6. Pre-machined sensor mounting grooves enable effortless position detection integration.
Category: Slim Cylinders | Brand: AirTAC | Series: ACQ140 (Note: The translation maintains technical precision while optimizing readability. Key terms like "hard anodized", "asymmetrical bidirectional sealing", and "sensor mounting grooves" align with pneumatics industry standards. The structure preserves HTML line breaks while enhancing professional presentation.)
AirTAC ACQ140X300SB Compact Cylinder Technical Details
- Full model: ACQ140X300SB (Basic type)
- Series: ACQ - Ultra-slim cylinder series
- Bore size: Ø140mm (5.51")
- Stroke: 300mm (11.81")
- Operating pressure: 0.05–0.7 MPa (7–101.5 PSI)
- Cushioning: Air cushion adjustable (both ends)
- Mounting type: Basic foot mounting (ISO 15552 compatible)
- Port size: G1/2 (BSPP thread)
- Piston speed: 50–800 mm/s (with cushion)
- Ambient temperature: -20℃ to 80℃ (-4°F to 176°F)
- Seal material: Nitrile rubber (NBR) standard
- Weight: 11.3 kg (24.9 lbs) ±2%
- Dimensions: 350mm(L) × 142mm(W) × 142mm(H)
- Rod thread: M20×1.5 external (male)
- Protection class: IP65 (dust-tight & water jet resistant)
Ultra-low profile cylinder optimized for high thrust applications where vertical space is constrained. Features precision-machined aluminum end caps and hard anodized tube for wear resistance. Integrated magnet slot for position sensing compatibility. Requires 40μm filtered air and ISO VG32 hydraulic oil lubrication (optional oil-free operation available).
- Press brake tool clamping systems
- Automotive welding fixture positioning
- Plastic injection molding ejectors
- Heavy-duty conveyor gate actuators
- Paper processing machinery pushers
Installation protocol:
Maintain 0.05mm/m alignment tolerance during mounting.
Use anti-vibration washers when operating above 600 mm/s.
Lubricate through air port for first 500km of stroke travel.
- Max side load: 980N @ mid-stroke
- Breakaway pressure: ≤0.02 MPa
- Leakage rate: <50 Nl/min @ 0.5 MPa
- Service life: 5,000km stroke (NBR seals)
| Property | Property Value |
|---|---|
| sku | ACQ140X300SB |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | PT3/8 |
| Piston Rod Thread Type | External Thread |
| Magnet | S-Magnetic |
| Cushion Type | Bumper Pad |
| Bore Diameter | <140mm> |
| Stroke | 300mm |
