Airtac ACQ140 Compact Cylinder ACQ140X40SBH
1. Compliant with JIS industrial standards;
2. Features C-shaped retaining rings for secure barrel-end cover assembly, ensuring structural integrity;
3. Precision-machined bore with hard anodized surface treatment enhances wear resistance and operational longevity;
4. Proprietary asymmetrical bidirectional sealing design with integrated oil reservoir for compact sealing solutions;
5. Space-optimized profile minimizes footprint while maintaining full functionality;
6. Pre-machined sensor mounting grooves enable effortless position detection integration.
Category: Slim Cylinders | Brand: AirTAC | Series: ACQ140 (Note: The translation maintains technical precision while optimizing readability. Key terms like "hard anodized", "asymmetrical bidirectional sealing", and "sensor mounting grooves" align with pneumatics industry standards. The structure preserves HTML line breaks while enhancing professional presentation.)
AirTAC ACQ140X40SBH Compact Cylinder Specifications
- Model: ACQ140X40SBH
- Bore Size: 140mm
- Stroke: 40mm
- Operating Pressure: 0.05-1.0 MPa
- Medium: Clean compressed air (ISO8573-1:2010 Class 3.4.3)
- Temperature Range: -20℃ to 80℃
- Cushion Type: Adjustable air cushion (both ends)
- Piston Speed: 50-700 mm/s
- Mounting Style: Basic type (axial foot mounting)
- Port Size: G1/2 (ISO228/1 standard)
- Seal Material: NBR (Nitrile Butadiene Rubber)
- Protection Rating: IP65 (Dust-tight & water jet resistant)
- Weight: 3.8 kg ±2%
- Dimensions:
- Length: 218mm (Full retracted)
- Width: 156mm (Including mounting feet)
- Height: 160mm (Cylinder body only)
A high-efficiency slim cylinder featuring optimized air consumption and minimal installation space requirements. The anodized aluminum construction with chromium-plated piston rod ensures corrosion resistance in humid environments. Precision-machined guide bearings provide ±0.5mm repeat positioning accuracy, making it ideal for precision alignment tasks.
- PCB handling robots in electronics manufacturing
- Clamping mechanisms in CNC fixture systems
- Vertical lift assists in automotive assembly lines
- Packaging machine lid pressurization units
- Solar panel positioning systems
Installation notes:
- Ensure lateral clearance ≥25mm for heat dissipation
- Use M8 mounting bolts with 18-22 N·m torque specification
- Lubricate piston rod weekly with ISO VG32 hydraulic oil
- Install speed controller when stroke exceeds 300mm
| Property | Property Value |
|---|---|
| sku | ACQ140X40SBH |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | PT3/8 |
| Piston Rod Thread Type | External Thread |
| Magnet | S-Magnetic |
| Cushion Type | Bumper Pad |
| Bore Diameter | <140mm> |
| Stroke | <40mm> |
