Airtac ACQ140 Compact Cylinder ACQ140X75SB
1. Compliant with JIS industrial standards;
2. Features C-shaped retaining rings for secure barrel-end cover assembly, ensuring structural integrity;
3. Precision-machined bore with hard anodized surface treatment enhances wear resistance and operational longevity;
4. Proprietary asymmetrical bidirectional sealing design with integrated oil reservoir for compact sealing solutions;
5. Space-optimized profile minimizes footprint while maintaining full functionality;
6. Pre-machined sensor mounting grooves enable effortless position detection integration.
Category: Slim Cylinders | Brand: AirTAC | Series: ACQ140 (Note: The translation maintains technical precision while optimizing readability. Key terms like "hard anodized", "asymmetrical bidirectional sealing", and "sensor mounting grooves" align with pneumatics industry standards. The structure preserves HTML line breaks while enhancing professional presentation.)
AirTAC ACQ140X75SB Thin-Type Cylinder Specifications
- Model: ACQ140X75SB
- Type: Compact ISO 6432 standard cylinder (double-acting)
- Bore size: Φ140mm
- Stroke: 75mm (±0.5mm tolerance)
- Operating pressure: 0.1–0.9 MPa
- Port size: G3/8 (M14×1.5 thread optional)
- Cushioning: Adjustable pneumatic cushion (both ends)
- Mounting style: Basic type (standard) with optional accessories for MF1/MF2 flange or MY1B foot mounting
- Temperature range: -20℃ to 80℃ (NBR seals)/-10℃ to 60℃ (optional FKM seals)
- Piston speed: 50–750 mm/s (lubricated)
- Seal material: Standard NBR (FDA compliant options available)
- Protection rating: IP40 (IP67 with optional wiper seal)
- Weight: 3.2kg ±5% (excluding accessories)
- Dimensions: 224mm(L) × 140mm(W) × 143mm(H) (at mid-stroke position)
Ultra-low profile cylinder featuring a 33% reduced height compared to standard models, with hardened anodized aluminum barrel and chromium-plated piston rod. Integrated magnet for position sensing compatibility. Designed for high moment resistance with reinforced guide bush structure. Requires ISO VG32 or equivalent hydraulic oil mist lubrication (0.1cm³/min minimum).
- High-density automation cells in electronics assembly
- Vertical lift mechanisms in food packaging lines
- Precision clamping devices for CNC punch presses
- Cleanroom-compatible medical device actuators
- High-cycle textile machinery with space constraints
Installation note:
Ensure perpendicular load application within ±2° angular misalignment tolerance.
Use dynamic load calculation formula: F = P × A × 0.75 (safety factor).
Lubricate through air supply (0.3-1.0μm filter required) during first installation.
| Property | Property Value |
|---|---|
| sku | ACQ140X75SB |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | PT3/8 |
| Piston Rod Thread Type | External Thread |
| Magnet | S-Magnetic |
| Cushion Type | Bumper Pad |
| Bore Diameter | <140mm> |
| Stroke | 75mm |
