Airtac ACQ160 Slim Cylinder ACQ160X100S
1. Compliant with JIS standards;
2. C-shaped retaining ring secures cylinder body to front/rear covers, ensuring compact and robust construction;
3. Bore surface undergoes precision machining followed by hard anodizing treatment, delivering superior wear resistance and extended service life;
4. Asymmetric bidirectional sealing structure on piston provides space-efficient design with integrated oil reservoir feature;
5. Compact profile optimizes space utilization in confined installation environments;
6. Perimeter sensor grooves enable convenient magnetic switch mounting.
Category: Slim Cylinder | Brand: AIRTAC | Series: ACQ160 （Note: Key technical terms optimized for industry usage include "hard anodizing", "asymmetric bidirectional sealing", "oil reservoir feature", and "perimeter sensor grooves" to maintain professional accuracy while enhancing international readability.）
AirTAC ACQ160X100S Ultra-Thin Cylinder Specifications
- Model: ACQ160X100S
- Type: Single-acting spring return (push type)
- Bore size: 16mm
- Stroke: 100mm
- Operating pressure: 0.05–0.9 MPa
- Ambient temperature: -20℃ to 80℃
- Cushioning: Fixed rubber bumper
- Port size: M5x0.8 (standard) / NPT1/8 optional
- Piston material: Aluminum alloy with hard anodizing
- Rod material: SUS304 stainless steel
- Seal type: NBR rubber (oil-resistant)
- Mounting style: Basic type (no built-in mounts)
- Weight: 230g ±5%
- Dimensions:
- Body length: 112mm (excluding rod)
- Total length (extended): 212mm
- Width: 34mm
- Height: 34mm
Ultra-compact cylinder with 50% reduced profile compared to standard models, featuring precision-machined guide slots for anti-rotation stability. Integrated wear-resistant bushing extends service life to 3,000km under 0.5MPa. Requires ISO VG32 or equivalent hydraulic oil lubrication (not pre-lubricated).
- PCB handling robots in electronics manufacturing
- Dispenser head positioning in adhesive applications
- Medical device clamp mechanisms
- Automated wafer cassette elevators
- Compact packaging machine pushers
Installation note:
Maximum side load 5N. For vertical mounting, use auxiliary guide rails when stroke exceeds 80mm.
Lubricate through air port using 1-2 drops of oil every 50,000 cycles.
| Property | Property Value |
|---|---|
| sku | ACQ160X100S |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | PT3/8 |
| Piston Rod Thread Type | Internal Thread |
| Magnet | S-Magnetic |
| Cushion Type | Bumper Pad |
| Bore Diameter | 125mm |
| Stroke | 100mm |
