Airtac ACQ160 Slim Cylinder ACQ160X100SB
1. Compliant with JIS standards;
2. C-shaped retaining ring secures cylinder body to front/rear covers, ensuring compact and robust construction;
3. Bore surface undergoes precision machining followed by hard anodizing treatment, delivering superior wear resistance and extended service life;
4. Asymmetric bidirectional sealing structure on piston provides space-efficient design with integrated oil reservoir feature;
5. Compact profile optimizes space utilization in confined installation environments;
6. Perimeter sensor grooves enable convenient magnetic switch mounting.
Category: Slim Cylinder | Brand: AIRTAC | Series: ACQ160 （Note: Key technical terms optimized for industry usage include "hard anodizing", "asymmetric bidirectional sealing", "oil reservoir feature", and "perimeter sensor grooves" to maintain professional accuracy while enhancing international readability.）
AirTAC ACQ160X100SB Ultra-Thin Cylinder Specifications
- Model: ACQ160X100SB
- Series: ACQ (Compact Square Cylinder)
- Bore size: 16mm
- Stroke: 100mm
- Operation type: Double-acting
- Mounting style: Basic (Standard)
- Cushion type: Rubber bumper (Both ends)
- Material: Aluminum barrel, SUS304 piston rod
- Seal material: NBR (Nitrile rubber)
- Operating pressure: 0.15–0.8 MPa
- Ambient temperature: -20℃ to 80℃
- Port size: M5x0.8 (G1/8 optional)
- Piston speed: 50–700 mm/s
- Weight: 0.46 kg (with accessories)
- Dimensions: 180mm(L) × 25mm(W) × 60mm(H)
- ISO standard: 6432 (Compact cylinder specification)
- Built-in magnet: Yes (For magnetic sensor attachment)
The ACQ160X100SB features a 6mm ultra-thin wall design for space-constrained automation systems. Its anodized aluminum construction provides corrosion resistance, while the chrome-plated piston rod ensures smooth operation. The cylinder includes dual cushioning adjustment screws for precise end-position deceleration control. Requires 40μm filtered air with ISO 8573-1:2010 Class 4.2.3 standards.
- PCB handling robots in electronics manufacturing
- Medical device positioning mechanisms
- Packaging machine clamp actuators
- Semiconductor wafer transfer systems
- Automated door locking mechanisms
Installation note:
Lubricate piston rod with ISO VG32 hydraulic oil before initial use.
Maintain 0.5mm minimum clearance between magnetic sensor and cylinder body.
Avoid side loads exceeding 2N·m during operation.
| Property | Property Value |
|---|---|
| sku | ACQ160X100SB |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | PT3/8 |
| Piston Rod Thread Type | External Thread |
| Magnet | S-Magnetic |
| Cushion Type | Bumper Pad |
| Bore Diameter | 125mm |
| Stroke | 100mm |
