Airtac ACQ160 Slim Cylinder ACQ160X150S
1. Compliant with JIS standards;
2. C-shaped retaining ring secures cylinder body to front/rear covers, ensuring compact and robust construction;
3. Bore surface undergoes precision machining followed by hard anodizing treatment, delivering superior wear resistance and extended service life;
4. Asymmetric bidirectional sealing structure on piston provides space-efficient design with integrated oil reservoir feature;
5. Compact profile optimizes space utilization in confined installation environments;
6. Perimeter sensor grooves enable convenient magnetic switch mounting.
Category: Slim Cylinder | Brand: AIRTAC | Series: ACQ160 （Note: Key technical terms optimized for industry usage include "hard anodizing", "asymmetric bidirectional sealing", "oil reservoir feature", and "perimeter sensor grooves" to maintain professional accuracy while enhancing international readability.）
AirTAC ACQ160X150S Ultra-Slim Cylinder Specifications
- Series: ACQ160 (Compact Square Cylinder Series)
- Bore size: 16mm
- Stroke: 150mm
- Operating pressure: 0.15–0.8 MPa
- Operating temperature: -20℃ to 80℃
- Cushion type: Adjustable rubber cushion (both ends)
- Mounting style: Basic type (optional foot/mounting flange)
- Material: Aluminum alloy barrel, stainless steel piston rod
- Seal material: NBR (standard), optional Fluorocarbon seals
- Port size: M5x0.8 (G1/8 adapter available)
- Weight: 0.45kg (excluding accessories)
- Dimensions: 230mm(L) × 40mm(W) × 25mm(H)
- Rod thread: M6x1.0 (external thread at both ends)
- Max speed: 500mm/s
- ISO standard: 6432 (25mm square barrel)
Ultra-flat pneumatic cylinder optimized for space-constrained automation systems. Features a 25mm height profile for concealed installations and precision rod guidance system with integrated scrape ring. Pre-lubricated for immediate operation in clean environments (-20℃ to 80℃). Requires 40μm filtered air with 1-10% lubricating oil (ISO VG32 recommended).
- PCB handling robots in electronics assembly
- Medical device clamping mechanisms
- Automated packaging pusher systems
- 3C product testing equipment
- Cleanroom material transfer systems
- Precision glass panel positioning
Installation note:
Maintain ≤0.1mm/m alignment tolerance during mounting. For vertical installations exceeding 500mm/s speed,
add external shock absorbers. Lubricate every 2,000km of cumulative travel in dry environments.
| Property | Property Value |
|---|---|
| sku | ACQ160X150S |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | PT3/8 |
| Piston Rod Thread Type | Internal Thread |
| Magnet | S-Magnetic |
| Cushion Type | Bumper Pad |
| Bore Diameter | 125mm |
| Stroke | 150mm |
