Airtac ACQ160 Slim Cylinder ACQ160X150SB
1. Compliant with JIS standards;
2. C-shaped retaining ring secures cylinder body to front/rear covers, ensuring compact and robust construction;
3. Bore surface undergoes precision machining followed by hard anodizing treatment, delivering superior wear resistance and extended service life;
4. Asymmetric bidirectional sealing structure on piston provides space-efficient design with integrated oil reservoir feature;
5. Compact profile optimizes space utilization in confined installation environments;
6. Perimeter sensor grooves enable convenient magnetic switch mounting.
Category: Slim Cylinder | Brand: AIRTAC | Series: ACQ160 （Note: Key technical terms optimized for industry usage include "hard anodizing", "asymmetric bidirectional sealing", "oil reservoir feature", and "perimeter sensor grooves" to maintain professional accuracy while enhancing international readability.）
AirTAC ACQ160X150SB Ultra-Thin Cylinder Specifications
- Model: ACQ160X150SB
- Type: Ultra-thin compact cylinder (double-acting)
- Bore size: 16mm
- Stroke: 150mm
- Operating pressure: 0.05–1.0 MPa
- Ambient temperature: -20℃ to 80℃
- Port size: M5x0.8 (standard) or NPT1/8 (optional)
- Cushioning: Adjustable rubber buffer
- Mounting style: Basic type (axial mounting holes)
- Material: Aluminum alloy body, NBR seals
- Weight: 0.82kg ±2%
- Dimensions: 190mm(L) × 50mm(W) × 30mm(H)
- Piston rod material: Stainless steel (SUS304)
- Max speed: 500mm/s
- Protection rating: IP54 (standard), IP67 (optional)
Featuring a 20% slimmer profile than standard cylinders, the ACQ series achieves space optimization without compromising 16mm bore performance. Precision honed tube ensures ≤0.05mm inner diameter tolerance. Optional magnetic version (add "-M" suffix) supports position sensing. Lubrication-free design with self-retaining structure prevents piston rotation.
- High-density PCB assembly equipment
- Semiconductor wafer handling robots
- Medical device positioning mechanisms
- Packaging machine clamp actuators
- Automated test fixture pushers
Installation guidelines:
Maintain 0.5mm minimum clearance between cylinder and mounting surface for thermal expansion.
Use Loctite 243 on mounting screws (torque ≤2.5N·m). Lubricate with ISO VG32 turbine oil if
operating below -10℃.
| Property | Property Value |
|---|---|
| sku | ACQ160X150SB |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | PT3/8 |
| Piston Rod Thread Type | External Thread |
| Magnet | S-Magnetic |
| Cushion Type | Bumper Pad |
| Bore Diameter | 125mm |
| Stroke | 150mm |
