Airtac ACQ160 Slim Cylinder ACQ160X175SB
1. Compliant with JIS standards;
2. C-shaped retaining ring secures cylinder body to front/rear covers, ensuring compact and robust construction;
3. Bore surface undergoes precision machining followed by hard anodizing treatment, delivering superior wear resistance and extended service life;
4. Asymmetric bidirectional sealing structure on piston provides space-efficient design with integrated oil reservoir feature;
5. Compact profile optimizes space utilization in confined installation environments;
6. Perimeter sensor grooves enable convenient magnetic switch mounting.
Category: Slim Cylinder | Brand: AIRTAC | Series: ACQ160 （Note: Key technical terms optimized for industry usage include "hard anodizing", "asymmetric bidirectional sealing", "oil reservoir feature", and "perimeter sensor grooves" to maintain professional accuracy while enhancing international readability.）
AirTAC ACQ160X175SB Ultra-Slim Cylinder Specifications
- Model: ACQ160X175SB
- Type: Double-acting ultra-slim cylinder
- Bore size: 16 mm
- Stroke: 175 mm
- Operating pressure: 0.05–1.0 MPa
- Operating temperature: -20℃ to 80℃
- Cushion type: Fixed rubber buffer + adjustable cushion (optional)
- Port size: M5x0.8 (standard) / NPT1/8 (optional)
- Piston speed: 50–800 mm/s
- Seal material: NBR + special polyurethane blend
- Mounting style: Basic type (axial mounting holes)
- Rod end: Male thread M6x1.0
- Weight: 520 g ±2% (without accessories)
- Dimensions:
- Body width: 20 mm (ultra-slim profile)
- Extended length: 245 mm (175mm stroke + 70mm base)
- Height: 25 mm (including mounting lugs)
- ISO standard: Compliant with ISO 6432:2015
- Accessories: Auto switch mount slots (for SNS-L series sensors)
Engineered for space-constrained automation systems, the ACQ160X175SB combines high thrust force (98N at 0.5MPa) with a remarkably compact cross-section. Its anodized aluminum construction minimizes weight while maintaining rigidity, featuring integrated wear-resistant bands for extended service life. The cylinder operates effectively in high-cycle applications (up to 1.5 million cycles) with proper lubrication.
- PCB handling robots in electronics manufacturing
- Precision clamping in CNC tool changers
- Cartesian coordinate pick-and-place systems
- Medical device assembly with cleanroom requirements
- Overhead actuation in packaging machinery
Installation guidance:
For vertical mounting, use anti-drop locking nuts (ADN series). Lubricate with ISO VG32 turbine oil
during initial installation. Avoid side load exceeding 2N·m. Maintain 0.3mm minimum parallel
tolerance between rod and guide mechanisms.
| Property | Property Value |
|---|---|
| sku | ACQ160X175SB |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | PT3/8 |
| Piston Rod Thread Type | External Thread |
| Magnet | S-Magnetic |
| Cushion Type | Bumper Pad |
| Bore Diameter | 125mm |
| Stroke | 175mm |
