Airtac ACQ160 Slim Cylinder ACQ160X200SB
1. Compliant with JIS standards;
2. C-shaped retaining ring secures cylinder body to front/rear covers, ensuring compact and robust construction;
3. Bore surface undergoes precision machining followed by hard anodizing treatment, delivering superior wear resistance and extended service life;
4. Asymmetric bidirectional sealing structure on piston provides space-efficient design with integrated oil reservoir feature;
5. Compact profile optimizes space utilization in confined installation environments;
6. Perimeter sensor grooves enable convenient magnetic switch mounting.
Category: Slim Cylinder | Brand: AIRTAC | Series: ACQ160 （Note: Key technical terms optimized for industry usage include "hard anodizing", "asymmetric bidirectional sealing", "oil reservoir feature", and "perimeter sensor grooves" to maintain professional accuracy while enhancing international readability.）
AirTAC ACQ160X200SB Ultra-Slim Cylinder Technical Details
- Model: ACQ160X200SB
- Series: ACQ160 (Compact Square Cylinder Series)
- Bore size: 160mm
- Stroke: 200mm
- Operating pressure: 0.05–1.0 MPa
- Port size: M5x0.8 (Standard) / G1/8 (Optional)
- Piston speed: 50–700 mm/s
- Ambient temperature: -20℃ to 80℃
- Cushioning: Fixed cushion (Rubber buffer)
- Material:
- Cylinder tube: Aluminum alloy (hard anodized)
- Piston rod: Stainless steel (SUS304)
- Seals: NBR (Nitrile rubber)
- Weight: 4.8 kg (±2%)
- Dimensions:
- Length: 382mm (Stroke 200mm + Minimum length)
- Width: 175mm (Square body dimension)
- Height: 175mm
- Mounting types: MF1 (Front flange) / MP2 (Side lug) / MA3 (Rear pivot)
- ISO standard: 6431 (Enhanced version)
This ultra-low profile cylinder combines high thrust force (2,010N at 0.5MPa) with space-saving design, featuring 30% reduced cross-section compared to standard cylinders. Precision honed tube ensures ≤0.05mm inner diameter tolerance. Optional magnetic piston version (ACQ160X200SB-M) enables position sensing.
- Semiconductor wafer handling robots
- High-speed press brake tool changers
- Automotive welding fixture clamping
- Pharmaceutical blister packaging machines
- Elevator door locking mechanisms
Maintenance tip:
Lubricate with ISO VG32 hydraulic oil (1-2 drops per port monthly).
Avoid side load exceeding 200N. For vertical mounting,
use MA3 pivot base to prevent piston rod deflection.
| Property | Property Value |
|---|---|
| sku | ACQ160X200SB |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | PT3/8 |
| Piston Rod Thread Type | External Thread |
| Magnet | S-Magnetic |
| Cushion Type | Bumper Pad |
| Bore Diameter | 125mm |
| Stroke | <200mm> |
