Airtac ACQ160 Slim Cylinder ACQ160X300S
1. Compliant with JIS standards;
2. C-shaped retaining ring secures cylinder body to front/rear covers, ensuring compact and robust construction;
3. Bore surface undergoes precision machining followed by hard anodizing treatment, delivering superior wear resistance and extended service life;
4. Asymmetric bidirectional sealing structure on piston provides space-efficient design with integrated oil reservoir feature;
5. Compact profile optimizes space utilization in confined installation environments;
6. Perimeter sensor grooves enable convenient magnetic switch mounting.
Category: Slim Cylinder | Brand: AIRTAC | Series: ACQ160 （Note: Key technical terms optimized for industry usage include "hard anodizing", "asymmetric bidirectional sealing", "oil reservoir feature", and "perimeter sensor grooves" to maintain professional accuracy while enhancing international readability.）
AirTAC ACQ160X300S Ultra-Slim Cylinder Specifications
- Model: ACQ160X300S
- Type: Single-acting spring return (push type)
- Bore size: 16mm
- Stroke: 300mm
- Operating pressure: 0.1–0.9 MPa
- Operating medium: Clean air (Lubricated/N2 required)
- Cushioning: Adjustable buffer
- Mounting style: Basic type (MF1) with multiple mounting options
- Material: Aluminum alloy cylinder tube, stainless steel piston rod
- Seal material: NBR (Nitrile rubber)
- Ambient temperature: -20℃ to 80℃
- Weight: 0.65kg (excluding accessories)
- Dimensions: 30mm(W) × 30mm(H) × 345mm(L)
- Port size: M5x0.8 (standard), optional G1/8
- Piston speed: 50–800 mm/s
- Protection rating: IP54 (standard seals)
Ultra-compact profile cylinder optimized for space-constrained automation systems. Features anodized corrosion-resistant construction with precision honed inner bore for smooth operation. Requires 5μm filtered air and recommends ISO VG32 turbine oil lubrication. Spring chamber includes venturi-style silencer for noise reduction.
- PCB handling robots in electronics manufacturing
- Medical device assembly line actuators
- Packaging machine gripper positioning
- Automated test equipment with Z-axis motion
- Cleanroom material handling systems
Installation note:
Maximum side load capacity 8N. Use alignment couplers when stroke accuracy
exceeds ±0.5mm. For vertical mounting, add 10% extra force margin for spring
resistance compensation. Lubricate through air supply at 1-2 drops/m³.
| Property | Property Value |
|---|---|
| sku | ACQ160X300S |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | PT3/8 |
| Piston Rod Thread Type | Internal Thread |
| Magnet | S-Magnetic |
| Cushion Type | Bumper Pad |
| Bore Diameter | 125mm |
| Stroke | 300mm |
