Airtac ACQ160 Slim Cylinder ACQ160X30SH
1. Compliant with JIS standards;
2. C-shaped retaining ring secures cylinder body to front/rear covers, ensuring compact and robust construction;
3. Bore surface undergoes precision machining followed by hard anodizing treatment, delivering superior wear resistance and extended service life;
4. Asymmetric bidirectional sealing structure on piston provides space-efficient design with integrated oil reservoir feature;
5. Compact profile optimizes space utilization in confined installation environments;
6. Perimeter sensor grooves enable convenient magnetic switch mounting.
Category: Slim Cylinder | Brand: AIRTAC | Series: ACQ160 （Note: Key technical terms optimized for industry usage include "hard anodizing", "asymmetric bidirectional sealing", "oil reservoir feature", and "perimeter sensor grooves" to maintain professional accuracy while enhancing international readability.）
AirTAC ACQ160X30SH Ultra-Slim Cylinder Specifications
- Model: ACQ160X30SH
- Type: Double-acting ultra-slim cylinder with magnetic piston
- Bore size: 16 mm
- Stroke: 30 mm (±1.5mm tolerance)
- Operating pressure: 0.05–1.0 MPa
- Port size: M5x0.8 (dual ports)
- Cushioning: Adjustable rubber buffer
- Temperature range: -20℃ to 80℃
- Piston material: Aluminum alloy (hard anodized)
- Rod material: SUS304 stainless steel
- Seals: NBR (nitrile rubber)
- Weight: 0.24 kg (excluding accessories)
- Dimensions: 84mm(L) × 30mm(W) × 16mm(H) (compact height design)
- Mounting options: Basic type (no built-in mounts, requires separate bracket)
- Repeat accuracy: ±0.5mm
- Max theoretical thrust: 20.1N at 0.5MPa
- Air consumption: 6.03 cm³ per cycle
The ACQ160X30SH redefines space efficiency with its 16mm ultra-low profile height, delivering precise linear motion in confined spaces. Its non-rotating piston rod and integrated magnet enable position feedback compatibility. The chrome-plated rod and wear-resistant seals ensure 3,000km+ service life under standard conditions.
- PCB handling robots in electronics manufacturing
- Precision clamping in optical lens assembly
- Valve actuation in portable medical analyzers
- Z-axis positioning in 3D printing extruders
- Compact automation in semiconductor wafer handling
Installation guidance:
Maintain 0.5-1mm clearance between magnetic sensor and cylinder body.
Lubricate with ISO VG32 turbine oil if used without air lubricator.
Avoid lateral loads exceeding 2N to prevent rod deflection.
| Property | Property Value |
|---|---|
| sku | ACQ160X30SH |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | PT3/8 |
| Piston Rod Thread Type | Internal Thread |
| Magnet | S-Magnetic |
| Cushion Type | Bumper Pad |
| Bore Diameter | 125mm |
| Stroke | 30mm |
