Airtac ASE Single Acting Plunger Type Compact Air Cylinder ASE100X5B
2. Threaded connection between cylinder body and front/rear covers delivers robust construction and easy maintenance;
3. Precision-machined bore with hard anodized treatment for superior wear resistance and extended service life;
4. Asymmetric bidirectional piston seal design combines compact dimensions with integrated oil reservoir functionality;
5. Space-saving profile achieves 50% more compact installation space compared to ISO 15552 standard cylinders of equivalent bore size;
6. Triple-side sensor slots enable tool-free sensor installation;
7. Integrated cushioning system effectively absorbs residual energy from high-speed operations and mechanical rotation;
8. Multiple configurable mounting accessories available for diverse applications.
Category: Compact Cylinders | Brand: AirTAC | Series: ASE
AirTAC ASE100X5B Single-Acting Compact Cylinder Specifications
- Model: ASE100X5B
- Type: Single-acting spring return (push type)
- Bore size: Ø100 mm
- Stroke: 5 mm (standard) with ±0.5mm tolerance
- Operating pressure: 0.1–0.8 MPa
- Piston speed: 50–750 mm/s (lubricated)
- Cushioning: Adjustable rubber bumper
- Mounting style: Basic type (standard foot mounting)
- Port size: G3/8 (ISO 228/1 standard)
- Seal material: NBR (nitrile butadiene rubber)
- Ambient temperature: -20℃ to +80℃
- Piston rod material: Stainless steel (SUS304)
- Tubing material: Anodized aluminum alloy
- Weight: 3.2 kg (without accessories)
- Dimensions: 196mm(L) × 100mm(W) × 108mm(H)
- ISO standard: 6431 (mounting dimensions compliant)
High-precision compact cylinder optimized for short-stroke pushing applications, featuring a reinforced rod-end bearing structure that reduces lateral load stress by 30% compared to standard models. The double-seal design ensures IP54-rated dust/water resistance. Requires 20μm filtered air and ISO VG32 turbine oil lubrication for optimal performance.
- Precision stamping machine ejection systems
- PCB board press-fit mechanisms
- Automotive part alignment fixtures
- Food packaging valve actuation
- Textile machinery thread tension control
Installation guidelines:
Maintain ≤0.1mm perpendicularity tolerance between rod axis and load direction.
For vertical mounting, use auxiliary guide mechanisms when lateral force exceeds 15N.
Lubricate every 3,000km of cumulative stroke movement.
| Property | Property Value |
|---|---|
| sku | ASE100X5B |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20-70°C Speed Range: 50-500 mm/s |
| Port Size | G1/8 |
| Piston Rod Thread Type | External Thread |
| Magnet | Non-magnetic |
| Bore Diameter | 100mm |
| Stroke | <5mm> |
