Airtac ASE Single Acting Plunger Type Compact Air Cylinder ASE12X10B
2. Threaded connection between cylinder body and front/rear covers delivers robust construction and easy maintenance;
3. Precision-machined bore with hard anodized treatment for superior wear resistance and extended service life;
4. Asymmetric bidirectional piston seal design combines compact dimensions with integrated oil reservoir functionality;
5. Space-saving profile achieves 50% more compact installation space compared to ISO 15552 standard cylinders of equivalent bore size;
6. Triple-side sensor slots enable tool-free sensor installation;
7. Integrated cushioning system effectively absorbs residual energy from high-speed operations and mechanical rotation;
8. Multiple configurable mounting accessories available for diverse applications.
Category: Compact Cylinders | Brand: AirTAC | Series: ASE
AirTAC ASE12X10B Single-Acting Compact Cylinder Specifications
- Model: ASE12X10B
- Type: Single-acting spring return (push-out type)
- Bore size: 12mm
- Stroke: 10mm
- Operating pressure: 0.05–0.9 MPa
- Temperature range: -10℃ to 70℃
- Port size: M5x0.8 (Dual ports)
- Cushioning: Adjustable rubber buffer
- Mounting style: Front flange (standard), optional foot mount
- Piston material: Aluminum alloy with hard anodizing
- Rod material: Stainless steel (SUS304)
- Seal material: NBR (Nitrile rubber)
- Weight: 0.25kg (without accessories)
- Dimensions: 80mm(L) × 34mm(W) × 34mm(H) (at full retraction)
- Protection rating: IP54 (standard), IP67 optional
- Lubrication: Pre-lubricated (Dry operation allowed)
A space-saving cylinder with precision-machined guide mechanism, featuring a unique dual-port design for faster exhaust. The chrome-plated piston rod and self-compensating seals ensure smooth operation in high-cycle applications (up to 1.5 million cycles). Requires 5μm filtered air with ISO 8573-1:2010 Class 3.2.2 air quality.
- PCB board clamping in SMT machines
- Precision valve actuation in coffee dispensers
- Paper feed mechanisms in POS printers
- Tool positioning in semiconductor wafer handlers
- Door locking systems in cleanroom equipment
Installation tip:
For vertical mounting, maintain ≤0.5mm alignment tolerance.
Use lock nuts (ASNU5-M5) when mounting in vibration-prone environments.
Lubricate every 3 million cycles using ISO VG32 hydraulic oil.
| Property | Property Value |
|---|---|
| sku | ASE12X10B |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20-70°C Speed Range: 50-500 mm/s |
| Port Size | M5×0.8 |
| Piston Rod Thread Type | External Thread |
| Magnet | Non-magnetic |
| Bore Diameter | 12mm |
| Stroke | <10mm> |
