Airtac ASE Single Acting Plunger Type Compact Air Cylinder ASE12X5B
$27.41
Regular price
$34.91
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
ASE12X5B
Product type:
Tags:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. Compliance with ISO 21287 standard ensures high mounting dimension compatibility;
2. Threaded connection between cylinder body and front/rear covers delivers robust construction and easy maintenance;
3. Precision-machined bore with hard anodized treatment for superior wear resistance and extended service life;
4. Asymmetric bidirectional piston seal design combines compact dimensions with integrated oil reservoir functionality;
5. Space-saving profile achieves 50% more compact installation space compared to ISO 15552 standard cylinders of equivalent bore size;
6. Triple-side sensor slots enable tool-free sensor installation;
7. Integrated cushioning system effectively absorbs residual energy from high-speed operations and mechanical rotation;
8. Multiple configurable mounting accessories available for diverse applications.
Category: Compact Cylinders | Brand: AirTAC | Series: ASE
Installation note:
For optimal performance, maintain 0.5-1mm clearance between rod end and load during mounting.
Lubricate with ISO VG32 hydraulic oil if used in non-lubricated systems. Maximum side load: 2.5N.
2. Threaded connection between cylinder body and front/rear covers delivers robust construction and easy maintenance;
3. Precision-machined bore with hard anodized treatment for superior wear resistance and extended service life;
4. Asymmetric bidirectional piston seal design combines compact dimensions with integrated oil reservoir functionality;
5. Space-saving profile achieves 50% more compact installation space compared to ISO 15552 standard cylinders of equivalent bore size;
6. Triple-side sensor slots enable tool-free sensor installation;
7. Integrated cushioning system effectively absorbs residual energy from high-speed operations and mechanical rotation;
8. Multiple configurable mounting accessories available for diverse applications.
Category: Compact Cylinders | Brand: AirTAC | Series: ASE
AirTAC ASE12X5B Single-Acting Compact Cylinder Specifications
- Model: ASE12X5B (ISO6432 compliant)
- Type: Single-acting spring return (push type)
- Bore size: 12mm
- Stroke: 5mm (standard, customizable 1-50mm)
- Operating pressure: 0.1–0.9 MPa
- Port thread: PT1/8 (NPT1/8 optional)
- Cushioning: Built-in rubber buffer
- Seal material: Nitrile rubber (NBR) standard, optional FKM
- Temperature range: -20℃ to 80℃
- Piston speed: 50-700 mm/s
- Weight: 0.11 kg (bare cylinder), 0.13 kg with accessories
- Dimensions:
- Body length: 38mm
- Total length (extended): 43mm
- Width: 24mm (mounting face)
- Height: 24mm (excluding rod)
- Rod diameter: 6mm
- Mounting: Basic type (no built-in mounts), accepts ISO6432 accessories
- Protection rating: IP65 (rod seal)
Ultra-compact cylinder optimized for precision short-stroke applications. Features anodized aluminum construction with chrome-plated piston rod. The T-slot design allows flexible sensor mounting. Requires 5μm filtered lubricated air (ISO8573-1 class 4).
Typical Applications:
- Micro-positioning in semiconductor handling robots
- Clamping mechanisms in SMT pick-and-place machines
- Valve actuation in portable medical analyzers
- Ejector systems in miniature molding presses
- Precision alignment in optical lens assembly
Installation note:
For optimal performance, maintain 0.5-1mm clearance between rod end and load during mounting.
Lubricate with ISO VG32 hydraulic oil if used in non-lubricated systems. Maximum side load: 2.5N.
Maintenance Cycle:
- Relubrication interval: 500km travel distance or 6 months
- Rod wiper replacement: 2 million cycles
- Seal replacement threshold: 10 million cycles (NBR)
| Property | Property Value |
|---|---|
| sku | ASE12X5B |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20-70°C Speed Range: 50-500 mm/s |
| Port Size | M5×0.8 |
| Piston Rod Thread Type | External Thread |
| Magnet | Non-magnetic |
| Bore Diameter | 12mm |
| Stroke | <5mm> |
