Airtac ASE Single Acting Plunger Type Compact Air Cylinder ASE16X10B
2. Threaded connection between cylinder body and front/rear covers delivers robust construction and easy maintenance;
3. Precision-machined bore with hard anodized treatment for superior wear resistance and extended service life;
4. Asymmetric bidirectional piston seal design combines compact dimensions with integrated oil reservoir functionality;
5. Space-saving profile achieves 50% more compact installation space compared to ISO 15552 standard cylinders of equivalent bore size;
6. Triple-side sensor slots enable tool-free sensor installation;
7. Integrated cushioning system effectively absorbs residual energy from high-speed operations and mechanical rotation;
8. Multiple configurable mounting accessories available for diverse applications.
Category: Compact Cylinders | Brand: AirTAC | Series: ASE
AirTAC ASE16X10B Single-Action Compact Cylinder Specifications
- Model: ASE16X10B
- Type: Single-acting spring return (push type)
- Bore size: 16mm
- Stroke: 10mm
- Operating pressure: 0.15–0.8 MPa
- Port size: M5x0.8 (dual ports)
- Piston speed: 50–700 mm/s
- Cushioning: Adjustable rubber bumper
- Mounting style: Front flange (optional rear flange)
- Ambient temperature: -20℃ to 80℃
- Seal material: Nitrile rubber (NBR)
- Weight: 0.12kg (excluding accessories)
- Dimensions: 100mm(L) × 40mm(W) × 40mm(H)
- Rod thread: M5×0.8 external thread
- Corrosion protection: Chromium-plated piston rod
- ISO standard: 6432 compliant
A space-saving pneumatic actuator optimized for linear motion in confined areas. Features precision-machined aluminum alloy construction with double-sealed piston for leak prevention. Requires dry compressed air (lubricated operation recommended for extended lifespan). Includes built-in auto-exhaust function for rapid spring return.
- PCB board clamping in electronics assembly
- Miniature part ejection in injection molding
- Valve actuation in medical devices
- Precision positioning in semiconductor handling
- Light-duty pressing operations
Installation note:
Maintain 0.5mm minimum clearance between rod end and workpiece. For vertical mounting,
use auxiliary guide mechanisms if lateral forces exceed 2N. Lubricate every 3 months
under continuous operation.
| Property | Property Value |
|---|---|
| sku | ASE16X10B |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20-70°C Speed Range: 50-500 mm/s |
| Port Size | M5×0.8 |
| Piston Rod Thread Type | External Thread |
| Magnet | Non-magnetic |
| Bore Diameter | 16mm |
| Stroke | <10mm> |
