This model is discontinued
AirTAC has phased out the MAL series. The drop-in replacement is ATE16X10S — same bore, stroke, output force, port and mounting, so it fits the same application. Simply order the ATE16X10S in place of this model. The ACE replacement is a current-production ISO 21287 compact cylinder in the same bore, stroke and force class, with a matching short body and the same mounting-accessory family, so it fits the same envelope. Confirm mounting-interface dimensions against the ACE datasheet before ordering.
Airtac ATP Single Acting Port Compact Cylinder ATP16X10S
The AirTAC Airtac ATP Single Acting Port Compact Cylinder ATP16X10S is a single acting, pull (spring return) DIN-standard tight/compact air cylinder with a Ø16mm bore and 10mm stroke, M5×0.8 air ports and a hard-anodized aluminium body. This model is discontinued — the current-production replacement is the ATE16X10S (ISO 21287 ACE), in the same bore, stroke and force class.
- BoreØ16 mm
- Stroke10 mm
- Port sizeM5×0.8
- Acting typeSingle acting, pull (spring return)
- Rod threadM4×0.7
- StatusDiscontinued → ATE16X10S
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac ATP Single Acting Port Compact Cylinder ATP16X10S
A single acting pull cylinder with spring return, the ATP16X10S keeps its 8 mm rod extended by spring and retracts it with air pressure from 0.2 MPa (28-145 psi) up to 1.0 MPa. Net of the return spring it delivers 53.3 N of pull at 0.5 MPa and 83.5 N at 0.7 MPa, so it suits light retraction and clamp-release work in a 16 mm bore. The hard-anodized aluminium body and S45C hard-chrome rod carry a fixed TPU bumper at both ends, and the -S code on this model means the magnet is fitted, so CMSE or DMSE reed and solid-state switches can be mounted directly on the body.
The short ISO 21287-class body saves roughly 50% of the mounting length of an ISO 15552 profile cylinder, which is why it fits inside tight jigs, small guards and compact gantries. For sizing, treat about 32 N (roughly 3.2 kg of pull) as the practical working force at 0.5 MPa, and expect it to lift about 2.7 kg vertically once a 2:1 margin is applied. Note that this model is discontinued: the current-production drop-in is the ATE16X10, same bore, stroke and force class - confirm ISO 21287 mounting dimensions before swapping.
Airtac ATP Single Acting Port Compact Cylinder ATP16X10S Technical Specifications
| Model | Airtac ATP Single Acting Port Compact Cylinder ATP16X10S |
|---|---|
| Series | ATP DIN compact cylinder (discontinued) |
| Replacement | ATE16X10S |
| Bore size | Ø16 mm |
| Stroke | 10 mm |
| Acting type | Single acting, pull (spring return) |
| Port size | M5×0.8 |
| Rod thread | M4×0.7 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.2 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 50 – 500 mm/s |
| Cushion | Fixed bumper (both ends) |
| Max standard stroke | Up to 25 mm |
Specifications follow the official AirTAC ACP datasheet (now discontinued). The ATE16X10S (ISO 21287) carries the same bore/stroke/force class; confirm mounting-interface dimensions against the ACE datasheet before installation. Rod type: female thread (blank) or male thread (B). Thread options: PT (blank) / G.
Theoretical Output Force (Ø16mm)
| Pressure | Pull force (spring return) |
|---|---|
| 0.5 MPa | 53.3 N |
| 0.7 MPa | 83.5 N |
Single-acting pull: the spring extends the rod; air retracts it. Forces already net the spring; minimum working pressure is 0.2 MPa.
Model Code: Airtac ATP Single Acting Port Compact Cylinder ATP16X10S
| ATP | DIN compact cylinder (single-acting pull, spring-return, discontinued). |
|---|---|
| 16 | Bore size in mm. |
| ×10 | Stroke length in mm. |
| S | Optional built-in magnet for sensor position sensing (omit for no magnet). |
| B | Rod type: B = male thread; blank = female thread. |
Replacement mapping (swap P for E): ACP→ACE, ASP→ASE, ATP→ATE, ACPD→ACED, ACPJ→ACEJ. ACP-family: ACP (double acting), ASP / ATP (single acting push / pull), ACPD (double rod), ACPJ (adjustable stroke).
Where the Airtac ATP Single Acting Port Compact Cylinder ATP16X10S Is Used
Fixture clamp release
Spring-extended hold on a small machined bracket, released by 53.3 N of air pull at 0.5 MPa when the valve fires - fails to the clamped position on air loss.
Position-flag retraction on a packaging line
The fitted -S magnet drives a CMSE switch so the PLC confirms the 10 mm retract of a light gate or chute flag at up to 500 mm/s.
Sample-lift in a compact lab module
Lifts about 2.7 kg vial trays vertically inside a tight enclosure where a full-length profile cylinder would not fit.
Replacing the Airtac ATP Single Acting Port Compact Cylinder ATP16X10S with the ATE16X10S
Size by force first: if 53.3 N of pull at 0.5 MPa is marginal for your part weight, step up to the ATP20X10S (88.1 N at 0.5 MPa); if it is well above your need, the ATP12X10 (25.9 N) saves space. The 10 mm stroke sits well inside the standard range for bore 16, so no made-to-order stroke is needed. The female M4x0.7 rod thread takes I/Y knuckles, and FA/FB flange, LB foot or CA/CB clevis mounts bolt to the same face. On air loss the spring returns the rod to its extended home position - it does not hold a mid-stroke point. Order the ATE16X10 as the current replacement and verify ISO 21287 mounting dimensions.
Replacement checklist
- ✓ Current-production ACE → ATE16X10S
- ✓ Same bore / stroke / force class
- ✓ Confirm ISO 21287 mounting dimensions
- ✓ Port/thread type (PT / G)
- ✓ Add -S for magnet if you need sensors
Airtac ATP Single Acting Port Compact Cylinder ATP16X10S FAQ
Net of the return spring: 53.3 N of pull at 0.5 MPa and 83.5 N at 0.7 MPa. Operating pressure is 0.2-1.0 MPa (28-145 psi), proof pressure 1.5 MPa (215 psi), speed 50-500 mm/s, temperature -20 to +70 C, and the minimum 0.2 MPa is what it takes to overcome the spring and retract the rod.
The short ISO 21287-class body saves about 50% of the mounting length of an ISO 15552 profile cylinder, with a fixed TPU bumper at each end. Because this model carries the -S code, the magnet is fitted and CMSE or DMSE reed or solid-state switches mount directly on the body. The model itself is discontinued - the ATE16X10 is the current drop-in, so confirm ISO 21287 mounting dimensions before ordering.
Request a Quote for the ATE16X10S
Send us the quantity and destination. We confirm price, stock and lead time on the ATE16X10S replacement — usually within 7-8 hours.
