Airtac B01-MA Special Cylinder B01-MA25X125SCA
AirTAC B01-MA25X125SCA Specialty Cylinder Technical Details
- Model Series: B01-MA (Compact ISO Cylinder Series)
- Bore Size: 25mm (0.98")
- Stroke: 125mm (4.92")
- Operation Type: Double Acting
- Working Pressure: 0.05-1.0 MPa (7-145 PSI)
- Cushioning: Adjustable Air Cushion (Both Ends)
- Piston Speed: 50-750 mm/s
- Ambient Temp Range: -20℃ to 80℃ (-4°F to 176°F)
- Port Size: M5x0.8 (Standard) / Optional NPT1/8
- Mounting: Basic Foot Mount (ISO 15552 Front Flange Optional)
- Material: Aluminum Barrel with Hard Anodized Piston Rod
- Seal Material: NBR (Nitrile) for General Use / Optional FKM
- Rod End Thread: M10x1.25 (Female)
- Protection Class: IP65 (Dust Tight & Water Jet Resistant)
- Weight: 1.43kg (3.15 lbs)
- Dimensions: 195mm(L) × 40mm(W) × 40mm(H)
High-precision industrial cylinder featuring wear-resistant chromium-plated piston rod and built-in magnet for position sensing compatibility. The dual adjustable cushioning system minimizes end-impact noise while maintaining positioning accuracy (±0.5mm repeatability). Sealed with low-friction guides for smooth operation in high-cycle applications (up to 5 million cycles @ 0.5 MPa).
- High-speed pick-and-place automation systems
- Pharmaceutical blister packaging machinery
- Semiconductor wafer handling robots
- Food-grade production lines (when paired with FDA-compliant seals)
- Plastic injection molding ejector mechanisms
Installation Guidelines:
Lubricate with ISO VG32 hydraulic oil before initial use. Avoid side load exceeding 15N.
For vertical mounting, install rod end downward to prevent condensate accumulation.
Maintain 0.3-1.0 MPa air pressure for optimal sensor performance.
| Property | Property Value |
|---|---|
| sku | B01-MA25X125SCA |
