Airtac B01-MA Special Cylinder B01-MA25X150SCA
AirTAC B01-MA25X150SCA Special Purpose Cylinder Technical Details
- Series: B01-MA Dedicated Cylinder Line
- Full Model: B01-MA25X150SCA
- Bore Size: Ø25mm (0.98in)
- Stroke: 150mm (5.91in)
- Action Type: Double-acting with auto-reverse
- Operating Pressure: 0.05-1.0MPa (7-145psi)
- Cushioning: Adjustable air cushion (both ends)
- Piston Speed: 50-700mm/s (lubricated)
- Mounting Style: Basic front flange (SCA-type)
- Rod Thread: M10×1.25 male thread
- Port Size: G1/8 (NPT1/8 optional)
- Seal Material: Polyurethane (NBR seals optional)
- Ambient Temp: -10℃ to 80℃ (14°F to 176°F)
- Weight: 0.82kg (1.81lbs)
- Dimensions: 200mm(L) × 50mm(W) × 50mm(H)
- Rod End: Female clevis included
- Position Detection: Magnet detectable (Φ5×4mm magnet)
High-precision industrial cylinder with chromium-plated piston rod and aluminum alloy body, featuring wear-resistant guide bushings. Designed for vertical load applications requiring precise stroke control. Requires ISO VG32 or equivalent hydraulic oil lubrication for optimal performance.
- Semiconductor wafer handling robots
- Pharmaceutical tablet pressing machines
- Precision glass cutting systems
- Automated optical inspection equipment
- High-cycle packaging line actuators
Installation advisory:
Mount using M5×0.8 flange screws with 20N·m torque limit.
Maintain 0.5mm minimum alignment tolerance between rod and load.
Perform 500km stroke maintenance inspection.
| Property | Property Value |
|---|---|
| sku | B01-MA25X150SCA |
