Airtac B01-MALJ Special Application Cylinder B01-MALJ40X175-50S
AirTAC B01-MALJ40X175-50S Special Purpose Cylinder Specifications
- Series: B01-MALJ Compact Guided Cylinder
- Full model: B01-MALJ40X175-50S
- Bore size: 40mm (ISO 6432 standard)
- Stroke: 175mm (±0.5mm tolerance)
- Rod diameter: 12mm (chrome-plated steel)
- Operating pressure: 0.05-1.0 MPa
- Ambient temperature: -20℃ to 80℃
- Cushioning: Adjustable pneumatic cushion (both ends)
- Mounting type: MF1 standard flange (ISO 15552 compatible)
- Port size: M5x0.8 (dual ports at both ends)
- Seal material: NBR (nitrile rubber)
- Piston material: Aluminum alloy with hard anodizing
- Weight: 1.62kg (without accessories)
- Dimensions: 302mm(L) × 50mm(W) × 50mm(H) (fully retracted)
- Max thrust: 503N @ 0.63MPa
- Max speed: 500-800mm/s (with cushion adjustment)
- Protection class: IP54 (standard wiper seal)
- Position detection: Built-in magnet (SMCR8-10 compatible)
High-precision guided cylinder with integrated anti-rotation mechanism, featuring dual linear ball bearings for exceptional lateral load capacity. The hardened piston rod and multi-layered sealing system ensure reliable operation in high-cycle applications. Requires ISO 8573-1:2010 Class 3 compressed air.
- Precision alignment in semiconductor handling equipment
- Vertical lifting mechanisms for automated packaging lines
- Clamping fixtures for CNC machining centers
- Material transfer arms in cleanroom environments
- Press-fit operations in automotive assembly
Installation recommendation:
Maintain 0.5-1mm alignment tolerance during mounting. Use locknuts (included)
with 2.5-3.5Nm torque. Lubricate with ISO VG32 hydraulic oil during initial setup.
| Property | Property Value |
|---|---|
| sku | B01-MALJ40X175-50S |
