Airtac B52-ACE Non-Copper Compact Cylinder B52-ACE50X50SB
The AirTAC Airtac B52-ACE Non-Copper Compact Cylinder B52-ACE50X50SB is a genuine double acting ISO 21287 compact air cylinder with a Ø50mm bore and 50mm stroke, 1/8" air ports and a hard-anodized aluminium body. Its short compact envelope saves about 50% of the mounting length of an ISO 15552 profile cylinder.
- BoreØ50 mm
- Stroke50 mm
- Port size1/8"
- Acting typeDouble acting
- Rod threadM10×1.5
- CushionFixed TPU bumper (both ends)
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac B52-ACE Non-Copper Compact Cylinder B52-ACE50X50SB
This is a double acting ISO 21287 compact cylinder, the B52-ACE50X50SB, with a 50 mm bore and a 50 mm stroke. Its hard-anodized aluminium body is about 50% shorter than an ISO 15552 profile cylinder, so it fits into tight jigs and guarded machine zones where a full-length unit will not. The 16 mm hard-chrome rod delivers a 981.7 N push and 881.2 N pull at 0.5 MPa, and the fixed TPU bumper at each end absorbs end-of-stroke impact without any adjustment.
The B52- prefix marks AirTAC's copper-free (copper-prohibited) build of the ACE50X50SB, intended for lines where copper and copper alloys are not allowed, such as ammonia systems or certain battery and chemical plants. This model carries the optional -S magnet, so CMSE or DMSE reed and solid-state switches can be mounted for position sensing. For a real workload at 0.5 MPa, plan on about 589 N of usable force, which lifts roughly 60 kg vertically with a 2:1 safety margin; confirm the exact copper-free material substitutions with us before ordering.
Airtac B52-ACE Non-Copper Compact Cylinder B52-ACE50X50SB Technical Specifications
| Model | Airtac B52-ACE Non-Copper Compact Cylinder B52-ACE50X50SB |
|---|---|
| Series | ACE compact cylinder |
| Standard | ISO 21287 |
| Bore size | Ø50 mm |
| Stroke | 50 mm |
| Acting type | Double acting |
| Port size | 1/8" |
| Rod thread | M10×1.5 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 500 mm/s |
| Cushion | Fixed TPU bumper (both ends) |
| Max standard stroke | Up to 250 mm |
Specifications follow the official AirTAC ACE-series (ISO 21287) datasheet. Body: hard-anodized aluminium alloy; piston rod: S45C carbon steel with hard-chrome plating. Rod type: female thread (blank) or male thread (B). Thread options: PT (blank) / G. A built-in magnet is OPTIONAL — add the -S code to fit CMSE / DMSE position sensors.
Theoretical Output Force (Ø50mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 982 N | 881 N |
| 0.7 MPa | 1374 N | 1234 N |
| Max (@1.0 MPa) | 200 kgf | |
Actual usable force is lower than theoretical due to friction and back-pressure. Size with a safety margin.
Model Code: Airtac B52-ACE Non-Copper Compact Cylinder B52-ACE50X50SB
| ACE | ISO 21287 compact cylinder (double-acting). |
|---|---|
| 50 | Bore size in mm. |
| ×50 | Stroke length in mm. |
| S | Optional built-in magnet for CMSE / DMSE sensors (omit for no magnet). |
| B | Rod type: B = male thread; blank = female thread. |
ACE-family variants: ACE (double acting), ASE / ATE (single acting push / pull), ACED (double rod), ACEJ (adjustable stroke), TACE / TACED (non-rotating twin-guide yoke). Mounting accessories: FA / FB flange, LB foot, CA / CB clevis, CR, SDB pivot, FTC; plus I and Y knuckles. Thread PT (blank) / G.
Where the Airtac B52-ACE Non-Copper Compact Cylinder B52-ACE50X50SB Is Used
Battery Cell Clamping
In a battery assembly line, this 50 mm bore compact cylinder with a 50 mm stroke clamps cell holders during tab welding, delivering 981.7 N of push at 0.5 MPa while fitting inside a guarded fixture.
Conveyor Stop Gate
Use it as a stop gate on a light conveyor in a chemical plant, where the copper-free build avoids contamination risk. The 50 mm stroke lifts a 60 kg load vertically with margin, and the fixed TPU bumper handles repeated cycling.
Ammonia Test Rig
In an ammonia-based refrigeration test rig, this copper-free cylinder actuates a small valve lever. The 1/8" port connects to filtered air, and the optional magnet lets a CMSE switch confirm the lever position.
Is the Airtac B52-ACE Non-Copper Compact Cylinder B52-ACE50X50SB the Right Cylinder?
Size this 50 mm bore unit against a 40 mm bore (628.3 N push at 0.5 MPa) if your load is lighter, or step up to a 63 mm bore (1558.6 N push at 0.5 MPa) for a heavier push. The 50 mm stroke suits short transfer slides and clamping actions, and the male rod thread (B) simplifies coupling to a clevis or rod end. Since the magnet is fitted, order CMSE or DMSE switches for position feedback; without the -S code, no magnet would be present. For a load that must stay put when air is lost, add a rod lock or pilot check valve, as this cylinder does not hold position on its own.
Quick checklist
- ✓ Required force at your working pressure
- ✓ Short stroke fits the compact body
- ✓ Port/thread type (PT / G)
- ✓ Add -S if you need the magnet for sensors
- ✓ Rod type (female / male B) & mount (FA/LB/CA)
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Compact body: keep the stroke short and avoid side load on the rod.
- check Do not dismantle the threaded front/back covers.
- check Keep speed within the rated range; the TPU bumper absorbs stroke-end energy.
- check Installation by qualified personnel per AirTAC docs.
Airtac B52-ACE Non-Copper Compact Cylinder B52-ACE50X50SB FAQ
At 0.5 MPa, the push force is 981.7 N and the pull force is 881.2 N. At 0.7 MPa, push is 1374.4 N and pull is 1233.7 N. The theoretical maximum force is 200.2 kgf at 1.0 MPa. The operating pressure range is 0.15-1.0 MPa (22-145 psi), with a proof pressure of 1.5 MPa (215 psi).
The B52- prefix designates AirTAC's copper-free (copper-prohibited) version of the ACE50X50SB, for applications where copper alloys are not permitted, such as ammonia systems. The body is an ISO 21287 compact design, about 50% shorter than an ISO 15552 profile cylinder, so it saves mounting space. The fixed TPU bumper at both ends absorbs end-of-stroke energy, and the optional -S magnet enables CMSE or DMSE switch mounting. Confirm the exact material substitutions with us for your specific media.
