Airtac B52-GF Copper-Free Pneumatic Air Treatment Component B52-GF40015JW
AirTAC B52-GF40015JW Copper-Free Air Treatment Unit Specifications
- Model: B52-GF40015JW
- Type: 3-in-1 FRL unit (Filter-Regulator-Lubricator)
- Port size: G1/4 (ISO standard)
- Operating pressure: 0.15–1.0 MPa
- Maximum flow: 1500 L/min
- Filtration grade: 40μm (5μm optional element available)
- Pressure gauge: Built-in 1/8" dial gauge (0-1.6 MPa range)
- Body material: Aluminum alloy (copper-free design)
- Seal material: NBR/HNBR optional
- Temperature range: -20℃ to 70℃
- Weight: 0.62 kg ±5%
- Dimensions: 150mm(L) × 65mm(W) × 90mm(H)
- Drain type: Semi-automatic float drain
- Lubricator capacity: 90cm³
- Pressure adjustment knob: Lockable rotary type
Copper-free triple-function air preparation unit combining precision filtration (with water separation), pressure regulation, and adjustable lubrication. Features anti-corrosion coating and tamper-proof adjustment for industrial environments. The copper-free construction prevents catalytic reactions in oxygen systems.
- Oxygen supply systems in medical gas networks
- Food processing pneumatic lines (copper contamination prevention)
- Semiconductor manufacturing cleanrooms
- Marine equipment with saltwater exposure
- Pharmaceutical production pneumatic controls
Installation note:
Install vertically with arrow marking aligned to airflow direction.
Maintain 200mm upstream straight piping for optimal filtration.
Lubricator should be filled with ISO VG32-grade oil only.
- Filter element replacement: Every 6 months or 2000 operational hours
- Drain valve inspection: Weekly (manual purge recommended in high humidity environments)
- Pressure gauge calibration: Annual verification required
| Property | Property Value |
|---|---|
| sku | B52-GF40015JW |
