Airtac B52-GF Copper-Free Pneumatic Air Treatment Component B52-GF400C15W
AirTAC B52-GF400C15W Non-Copper Pneumatic Filter Regulator Lubricator (FRL) Specifications
- Model: B52-GF400C15W
- Type: 3-in-1 Air Treatment Unit (Filter + Regulator + Lubricator)
- Port Size: G1/2" (BSPP Thread)
- Maximum Flow: 3,500 L/min (ANR)
- Operating Pressure: 0.15 - 1.0 MPa
- Filtration Grade: 40μm (5μm optional with micro-glass element)
- Pressure Gauge: 1/8" BSP Dial Type (0-1.6 MPa range)
- Auto Drain: Semi-automatic float drain
- Body Material: Aluminum alloy (copper-free design)
- Seal Material: NBR (Nitrile Rubber)
- Temperature Range: -5℃ to 60℃ (non-freezing conditions)
- Weight: 2.65 kg (dry, without lubricant)
- Dimensions: 198mm(H) × 150mm(W) × 102mm(D)
- Orientation: Universal mounting (vertical installation recommended)
- Pressure Adjustment: Lockable knob with hex-key override
Industrial-grade FRL unit specifically engineered for copper-sensitive pneumatic systems. Features a triple-stage filtration process with centrifugal separation, sintered bronze filter element, and coalescing membrane. The pressure regulator includes a tamper-proof adjustment knob and zero-leak diaphragm. Lubricator section utilizes adjustable oil-feed (2-10 drops/min) with transparent oil bowl.
- Semiconductor manufacturing equipment
- Medical gas control systems (copper-free requirement)
- Marine pneumatic controls (saltwater environment)
- Food processing automation lines
- High-cycle molding machines
Installation Guidelines:1. Install in sequence: Filter → Regulator → Lubricator (F→R→L configuration)
2. Maintain 30cm upstream straight piping for optimal filtration
3. Drain bowl requires weekly inspection in humid environments
4. Use ISO VG32 turbine oil for lubrication (max. 60% bowl capacity)
5. Avoid mounting near heat sources exceeding 80℃
| Property | Property Value |
|---|---|
| sku | B52-GF400C15W |
