Airtac B52-TR Copper-Free Twin Rod Cylinder B52-TR6X10S
AirTAC B52-TR6X10S Copper-Free Double Rod Cylinder Specifications
- Model: B52-TR6X10S
- Type: Double rod, non-rotating copper-free cylinder
- Bore size: 6mm (standard series)
- Stroke: 10mm (customizable up to 300mm)
- Operating pressure: 0.05–1.0 MPa
- Cushioning: Adjustable rubber buffers at both ends
- Material: Stainless steel piston rod (SUS304), aluminum alloy barrel
- Temperature range: -20℃ to 80℃
- Mounting style: Basic non-magnetic base (accessory brackets available)
- Port size: M5x0.8 dual ports with Rc1/8 adaptor option
- Weight: 0.23kg (bare cylinder), 0.31kg with accessories
- Dimensions: 100mm(L) × 20mm(W) × 20mm(H) (at full retraction)
- Rod diameter: 3mm (both rods)
- Max thrust: 3.1N at 0.5MPa (extend/retract)
Corrosion-resistant pneumatic cylinder engineered for environments prohibiting copper contamination. Features dual hardened stainless steel rods with anti-rotation design for precise linear motion. Sealed with FKM (Viton) O-rings for chemical resistance. Includes magnetic piston for position sensing compatibility.
- Semiconductor wafer handling systems
- Food processing/packaging machinery (meets NSF guidelines)
- Pharmaceutical tablet press automation
- Cleanroom robotic positioning arms
- Marine equipment controls (saltwater resistant)
Installation protocol:
Lubricate with ISO VG32 copper-free pneumatic oil before initial use.
Maintain 0.5mm minimum lateral clearance during alignment.
Requires 5μm filtration for optimal seal longevity.
| Property | Property Value |
|---|---|
| sku | B52-TR6X10S |
