Airtac BKC Bulkhead Lock Nut Union BKC0425-01
AirTAC BKC0425-01 Lock Nut Straight Connector Specifications
- Model: BKC0425-01
- Type: Compression fitting lock nut straight connector
- Body material: Nickel-plated brass (C3604)
- Thread specification: PT1/4 (BSPP)
- Seal material: HNBR (Hydrogenated Nitrile) O-ring
- Operating pressure: 0.05–1.5 MPa
- Temperature range: -20℃ to 150℃
- Proof pressure: 2.25 MPa
- Vibration resistance: ≤10 m/s² (5-2000Hz)
- Weight: 28±2g
- Dimensions: 25mm(L) × 16mm(W) × 16mm(H)
- Surface roughness: Ra ≤3.2μm (sealing areas)
- Thread engagement depth: 8.5±0.5mm
High-pressure resistant straight connector with double-sealing structure, featuring a 360° rotatable lock nut for flexible installation alignment. The corrosion-resistant nickel plating ensures durability in humid environments. Precision-machined threads meet ISO 1179-1 standards for bubble-tight sealing.
- Pneumatic tool air supply lines
- CNC machine coolant systems
- Industrial robot EOAT (End of Arm Tooling) connections
- Compressed air dryers and filters
- Hydraulic test bench plumbing
Installation guidelines:
Apply 0.8-1.2 N·m torque during assembly. Use thread sealant only on male threads,
avoiding contact with sealing surfaces. Perform pressure test at 1.25× working
pressure for 3 minutes post-installation.
| Property | Property Value |
|---|---|
| sku | BKC0425-01 |
