Airtac BKC Bulkhead Lock Nut Union BKC0425-01-S
AirTAC BKC Locknut Straight Connector BKC0425-01-S Technical Details
- Model: BKC0425-01-S
- Type: Locknut-style straight thread connector
- Thread Standard: Metric (M5×0.8 internal thread)
- Tube Compatibility: 4mm OD polyurethane/nylon tubing
- Body Material: Nickel-plated brass (C3604)
- Seal Material: NBR (Nitrile) rubber
- Pressure Rating: 0.05–1.0 MPa
- Temperature Range: -20℃ to 80℃ (continuous use)
- Peak Temperature: 120℃ (intermittent, max 30 mins)
- Weight: 28g ±1g
- Dimensions: 25mm(L) × 20mm(W) × 15mm(H)
- Surface Finish: Electroless nickel plating (8-12μm)
- Vibration Resistance: ≤50m/s² (ISO 10816-3 compliant)
- Reusable Cycles: ≥500 connections
Precision-engineered push-to-connect fitting with dual-stage sealing mechanism (radial compression + axial compression). Features anti-vibration locknut with 180° rotation stop and copper-alloy construction for EMI/RFI shielding compatibility. Includes built-in tube insertion depth gauge.
- High-cycle pneumatic tool connections
- Robotic arm end effector plumbing
- Medical gas line quick-disconnect systems
- Semiconductor fab equipment air supply
- Electric vehicle battery cooling systems
Installation protocol:
Hand-tighten locknut until resistance is felt, then apply 1/4 turn with wrench.
Maximum torque 1.2N·m. Always use tube cutter (not scissors) for clean end preparation.
Compatibility note:
Not recommended for hydrocarbon-based fluids or continuous steam exposure.
Requires annual seal inspection in food-grade applications.
