Airtac BKC Bulkhead Lock Nut Union BKC0425-M5
AirTAC BKC Series Locknut Straight Connector BKC0425-M5 Technical Details
- Model: BKC0425-M5
- Type: Locknut style straight-through connector
- Body material: Stainless steel SUS303
- Seal material: NBR (Nitrile Butadiene Rubber)
- Thread specification: M5×0.8 (ISO metric fine thread)
- Operating pressure: 0.05–1.0 MPa
- Temperature range: -20℃ to 80℃
- Port connection: Push-to-connect (for ø4mm OD tubing)
- Surface treatment: Natural anodized finish
- Leakage rate: ≤0.1 mL/min (at 0.5 MPa)
- Weight: 12.5g ±0.3g
- Dimensions: 25mm(L) × 16mm(W) × 10mm(H)
- Vibration resistance: 10–55Hz, 1.5mm amplitude
- IP rating: IP40 (non-weatherproof)
Precision-machined pneumatic connector featuring tool-free tube insertion with positive lock mechanism. The tapered thread design ensures secure sealing while allowing 360° rotational adjustment after installation. Optimized flow path reduces pressure drop by 18% compared to standard connectors.
- Modular pneumatic system assembly lines
- Robotic end-effector tooling connections
- Laboratory analytical instrument gas lines
- Semiconductor manufacturing equipment
- Compact sensor air supply interfaces
Installation guidance:
Apply 0.8–1.2 N·m torque during M5 thread fastening.
Ensure tubing is cut square and inserted fully until "click" engagement.
Not recommended for continuous rotation applications exceeding 50 RPM.
| Property | Property Value |
|---|---|
| sku | BKC0425-M5 |
