Airtac BKC Bulkhead Lock Nut Union BKC0425-M5-S
AirTAC BKC0425-M5-S Swivel Nut Straight Connector Specifications
- Model: BKC0425-M5-S
- Type: Reusable swivel nut straight connector
- Body material: Brass with nickel plating (anti-corrosion grade)
- Thread specification: M5×0.8 external thread (ISO 1179 standard)
- Tube OD compatibility: 4mm (flexible installation tolerance: ±0.2mm)
- Max working pressure: 1.5 MPa (15 bar)
- Temperature range: -20℃ to 80℃ (continuous operation)
- Seal material: Oil-resistant NBR rubber (70±5 Shore A hardness)
- Weight: 12g ±0.5g (including packaging)
- Dimensions: 25mm(L) × 8mm(W) × 8mm(H) (nut fully tightened)
- Thread engagement depth: 3.5mm (minimum recommended)
- Torque specification: 0.3-0.5 N·m (hand-tightening recommended)
Precision-engineered pneumatic connector featuring a 360° rotatable nut for stress-free tube alignment in compact installations. The electroplated brass construction ensures corrosion resistance in humid environments, while the dual-seal design (radial + axial compression) prevents air leakage under vibration-intensive conditions.
- Modular pneumatic circuit assembly in CNC machines
- Sensor air supply lines in semiconductor manufacturing
- Medical device pneumatic control systems
- High-cycle automation equipment requiring frequent maintenance
- Robotic end-effector tooling connections
Installation protocol:
Use two wrenches during assembly - hold body stationary with 8mm wrench while tightening nut with 10mm wrench.
Perform pressure test at 1.8MPa after installation. Re-torque after 50 operating hours.
| Property | Property Value |
|---|---|
| sku | BKC0425-M5-S |
