Airtac BKC Bulkhead Lock Nut Union BKC0604-01
$3.48
Regular price
$10.98
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
BKC0604-01
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
AirTAC BKC0604-01 Lock Nut Straight Connector Specifications
- Model: BKC0604-01
- Type: Compression fitting straight connector with lock nut
- Thread standard: Metric (M5x0.8)
- Tube OD compatibility: 4mm (6mm OD reinforced tubing optional)
- Material: Nickel-plated brass body
- Seal material: HNBR (Hydrogenated Nitrile) O-ring
- Max working pressure: 1.5 MPa (15 bar)
- Temperature range: -20℃ to 120℃ (continuous duty)
- Torque specification: 1.2-1.5 N·m (installation)
- Weight: 8.5g ±0.3g
- Dimensions: 23mm(L) × 10mm(W) × 10mm(H)
- Surface treatment: Electroless nickel plating (8-12μm thickness)
- Vibration resistance: ≤50m/s² (ISO 10816-3 compliant)
Precision-engineered straight connector featuring dual-stage sealing with a compression sleeve and lock nut mechanism. The chamfered entry design prevents tubing abrasion during installation. Rated for 500,000+ insertion cycles with proper maintenance.
Typical Applications:
- Pneumatic valve manifold interconnections
- CNC machine tool coolant line junctions
- Medical gas delivery systems
- Automated packaging equipment air circuits
- Semiconductor fab cleanroom pneumatic networks
Installation protocol:
Insert tubing until it bottoms out before tightening lock nut. Perform pressure test at 1.25× working pressure for 5 minutes post-installation. Replace O-ring every 3 years under continuous use.
Compatible with PU, nylon, and PFA tubing. Not recommended for hydrocarbon-based fluids or high-frequency flex applications (use swivel-type connectors instead).
| Property | Property Value |
|---|---|
| sku | BKC0604-01 |
