Airtac BKC Bulkhead Lock Nut Union BKC0604-01-S
AirTAC BKC Locknut Straight Connector BKC0604-01-S Technical Details
- Model: BKC0604-01-S
- Type: Push-in locknut straight fitting (male thread to tube)
- Thread specification: M5×0.8 external thread (ISO metric)
- Tube compatibility: Ø4mm polyurethane/nylon tubing
- Material: Nickel-plated brass body
- Seal material: NBR (Nitrile) O-ring
- Max working pressure: 1.5 MPa (217 psi)
- Temperature range: -20℃ to 80℃ (-4°F to 176°F)
- Weight: 16.5g ±0.5g
- Dimensions: 25mm(L) × 12mm(W) × 12mm(H)
- Surface roughness: Ra ≤3.2μm
- Vibration resistance: 10-55Hz, 1.5mm amplitude
- Protection rating: IP40 (non-weatherproof)
Precision-engineered straight connector with dual-stage sealing system (radial compression + axial compression). Features a 360° rotatable collar for tool-free tube installation and anti-vibration locknut design. The chrome-plated brass construction ensures 50,000+ insertion cycles with <0.1mL/min leakage at 0.7MPa.
- Modular pneumatic manifolds requiring space-saving connections
- Robotic arm end effectors with frequent position changes
- Medical equipment requiring hygienic smooth surfaces
- PLC-controlled automation systems with multiple branch lines
- Food processing machinery (NSF-compliant material version available)
Installation protocol:
Insert tube until it bottoms out (audible click), then hand-tighten locknut.
For pressurized systems ≥0.8MPa, use 1/8 turn with wrench.
Maximum angular misalignment tolerance: 3°.
| Property | Property Value |
|---|---|
| sku | BKC0604-01-S |
