Airtac BKC Bulkhead Lock Nut Union BKC0604-02
AirTAC BKC Locknut Straight Connector BKC0604-02 Technical Details
- Model: BKC0604-02
- Type: Push-to-connect locknut straight fitting
- Body material: Nickel-plated brass (ISO 1179 compliant)
- Seal material: HNBR (Hydrogenated Nitrile) with PTFE coating
- Port size: 6mm tube OD (1/4")
- Thread specification: M5×0.8 female thread (DIN 3852 standard)
- Operating pressure: 0.05-1.0 MPa (7-145 psi)
- Burst pressure: ≥3.0 MPa (435 psi)
- Temperature range: -20℃ to 120℃ (static) / -5℃ to 80℃ (dynamic)
- Weight: 28g ±0.5g
- Dimensions: 32mm(L) × 16mm(W) × 16mm(H)
- Installation torque: 1.2-1.5 N·m (recommended with torque wrench)
- Vibration resistance: 10-55Hz, 1.5mm amplitude
- Compliance: RoHS 2011/65/EU, REACH SVHC 219
Precision-engineered pneumatic connector featuring triple-seal technology (radial seal, axial seal, and thread seal) for leak-free performance in high-vibration environments. The rotating locknut design enables 360° adjustable orientation post-installation while maintaining seal integrity. Compatible with polyurethane and nylon tubing (hardness range 80-94 Shore A).
- Robotic arm pneumatic circuits requiring flexible routing
- CNC machine tool coolant line connections
- Semiconductor manufacturing gas delivery systems
- Mobile hydraulic equipment with frequent hose reconfiguration
- High-cycle automation stations with vibration damping needs
Installation protocol:
(1) Insert tube fully until "click" engagement (2) Hand-tighten locknut (3) Final tighten with wrench
at marked flat surfaces (4) Perform 3x pressure cycle test (0→1.0MPa) before full operation.
Never reuse sealing rings.
| Property | Property Value |
|---|---|
| sku | BKC0604-02 |
