Airtac BKC Bulkhead Lock Nut Union BKC0604-02-S
$11.13
Regular price
$18.63
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
BKC0604-02-S
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
AirTAC BKC0604-02-S Locknut Straight Connector Technical Details
- Model: BKC0604-02-S
- Type: Metric thread locknut straight connector
- Body material: Nickel-plated brass (standard) / PBT plastic (optional)
- Thread specification: M5×0.8 external thread (male)
- Tube OD compatibility: 4mm (flexible range 3.5-4.5mm)
- Operating temperature: -20℃ to 80℃
- Max working pressure: 1.5 MPa (15 bar)
- Burst pressure: ≥4.5 MPa
- Seal material: NBR (standard) / FKM (high-temp option)
- Surface roughness: Ra ≤3.2μm (sealing areas)
- Weight: 12g ±0.5g
- Dimensions: 30mm(L) × 8mm(Dia) × 8mm(Hex size)
- Vibration resistance: 10-2000Hz, 20m/s²
- Certification: RoHS compliant
Precision-engineered push-to-connect fitting with dual-stage sealing (radial + axial compression). Features anti-vibration teeth and color-coded collar (blue for air, red for vacuum). Includes integrated flow restrictor for controlled disconnection.
Primary Applications:
- Pneumatic cylinder port connections in automotive assembly lines
- Modular vacuum system installations for semiconductor handling
- Tool-free maintenance access in food processing equipment
- Robotic arm pneumatic circuit branch connections
- Medical gas line quick-disconnect points
Installation protocol:
Hand-tighten until resistance is felt, then apply 0.8-1.2Nm torque with 8mm wrench.
Use 1.5 wraps of PTFE tape on male threads for gas applications. Test at 110% working
pressure for 3 minutes post-installation.
Compatibility note:
Not suitable for ethylene glycol mixtures or hydraulic fluids. Maximum 500
connect/disconnect cycles recommended for seal integrity.
| Property | Property Value |
|---|---|
| sku | BKC0604-02-S |
