Airtac BKC Bulkhead Lock Nut Union BKC0604-03
AirTAC BKC Locknut Straight Connector BKC0604-03 Technical Details
- Model: BKC0604-03
- Type: Locknut-style straight-through push-to-connect fitting
- Thread specification: M5×0.8 external thread (male)
- Tube compatibility: 4mm OD polyurethane/nylon tubing
- Material: Brass (nickel-plated) body, PPS resin collar
- Seal material: HNBR (Hydrogenated Nitrile) O-ring
- Max working pressure: 1.5 MPa (217 psi)
- Temperature range: -20℃ to 80℃ (-4°F to 176°F)
- Vibration resistance: ≤10 Hz frequency, 1.5mm amplitude
- Pull-out strength: ≥50 N (with 4mm tube)
- Weight: 18.5g ±0.3g
- Dimensions: 30mm(L) × 12mm(W) × 12mm(H)
- Surface roughness: Ra ≤3.2μm (thread area)
- Certifications: RoHS compliant, REACH SVHC-free
Precision-engineered pneumatic connector featuring a 360° rotatable locknut for simplified installation in confined spaces. The dual-seal design combines metal-to-metal sealing (thread interface) with elastomer sealing (tube interface) for leak-free performance under pressure fluctuations. The anti-vibration collar prevents unintended disconnection in high-cycle applications.
- Robotic arm pneumatic tool changers
- CNC machine tool coolant line connections
- Semiconductor wafer handling vacuum systems
- Electric vehicle battery cooling circuits
- Packaging machine air knife assemblies
Installation protocol:
Hand-tighten locknut before final torque adjustment (recommended 0.7-1.2 N·m).
Always insert tubes perpendicularly until hearing an audible click. Perform
monthly collar inspections in high-vibration environments.
| Property | Property Value |
|---|---|
| sku | BKC0604-03 |
