Airtac BKC Bulkhead Lock Nut Union BKC0805-01
AirTAC BKC0805-01 Locknut Straight Connector Technical Details
- Model: BKC0805-01
- Type: Locknut-style straight-through pneumatic fitting
- Body material: Nickel-plated brass (standard) / Stainless steel optional
- Thread specification: PT1/8 (BSPP) female threads
- Tube OD compatibility: 8mm (metric) / 5/16" (imperial)
- Max working pressure: 1.5 MPa (217 psi)
- Temperature range: -20℃ to 80℃ (NBR seals) / -20℃ to 150℃ (FKM seals optional)
- Surface hardness: HV0.3 120-200 (nickel plating)
- Vibration resistance: ≤10 m/s² (ISO 10816-3)
- Weight: 28g ±1g
- Dimensions: 32mm(L) × 24mm(W) × 24mm(H)
- Thread engagement depth: 8.5mm
- Certification: RoHS compliant
Heavy-duty straight connector with anti-vibration locknut design, featuring dual sealing layers (O-ring + metal-to-metal contact). The 360° rotatable collar enables tool-free installation while maintaining secure tube retention. Nickel plating provides corrosion resistance in humid environments.
- High-pressure pneumatic lines in CNC machinery
- Modular pneumatic circuit assembly
- Vibration-prone equipment like stamping presses
- Coolant line connections in machining centers
- Vacuum system plumbing
Installation protocol:
Hand-tighten locknut until resistance is felt, then apply 1/4 turn with wrench.
Maximum torque 3.5 N·m. Use thread sealant only on male threads, never on tube ends.
| Property | Property Value |
|---|---|
| sku | BKC0805-01 |
