Airtac BKC Bulkhead Lock Nut Union BKC0805-02
AirTAC BKC0805-02 Female Locknut Straight Connector Specifications
- Model: BKC0805-02
- Type: Metric threaded locknut straight connector
- Thread specification: M8×1.0 external thread × Ø5mm tube OD
- Material: Lead-free brass (C37700) with electroless nickel plating
- Operating pressure: 0.05–1.5 MPa (7–217 psi)
- Temperature range: -20℃ to 100℃ (NBR seals)
- Seal material: NBR (Nitrile) rubber standard (FKM/Viton optional)
- Torque resistance: ≤30 N·m tightening torque
- Surface hardness: ≥HV200 (plated layer)
- Weight: 18.5±0.5g
- Dimensions: 40mm(L) × 12mm(Hex width) × 8mm(Tube insertion depth)
- Compliance: RoHS 2.0 compliant
Precision-machined connector featuring triple-sealing structure (thread seal, O-ring seal, and metal-to-metal seal) for leak-proof performance in dynamic pneumatic systems. The hexagonal collar design allows tool-free hand tightening while maintaining 360° rotatable tube orientation after installation.
- Modular pneumatic circuit assembly in robotics
- Vacuum pick-and-place systems requiring frequent reconfiguration
- Medical gas delivery equipment connections
- High-cycle automation with vibration resistance requirements
- Mobile hydraulic test bench setups
Installation protocol:
Cut tube end square (max 0.5° angular error), insert fully until tube bottom-out,
hand-tighten locknut first, then apply 1/4 turn with wrench.
Avoid thread sealant – use PTFE tape only if necessary.
| Property | Property Value |
|---|---|
| sku | BKC0805-02 |
