Airtac BKC Bulkhead Lock Nut Union BKC0805-02-S
AirTAC BKC Locknut Straight Connector BKC0805-02-S Technical Details
- Model: BKC0805-02-S
- Type: Metric thread locknut straight connector
- Thread specification: M5×0.8 (male thread) / M5×0.8 (female thread)
- Material: Brass with nickel plating (surface hardness ≥HV200)
- Seal material: NBR (Nitrile) O-ring
- Operating pressure: 0.05-1.0 MPa (standard), 1.5 MPa max (burst)
- Temperature range: -20℃ to 80℃ (with silicone seals: -40℃ to 100℃)
- Torque resistance: ≤1.2 N·m tightening torque
- Surface treatment: Electroplated zinc-nickel alloy (corrosion resistance >96hrs salt spray test)
- Weight: 8.5±0.3g
- Dimensions: 20mm(L) × 8mm(Ø) × 14mm(W across flats)
- Flow rate: 130 NL/min (at 0.5 MPa pressure drop)
- Vibration resistance: 10-60Hz, 1.5mm amplitude
Precision-engineered metric connector featuring double-locking mechanism with integrated anti-vibration design. The hexagonal body allows tool-free adjustment while maintaining 360° rotatable connection capability. Nickel-plated brass construction ensures corrosion resistance in humid environments, compatible with air, water, and non-corrosive gases.
- Modular pneumatic circuit assembly in robotics
- Sensor mounting in automated production lines
- Medical device gas delivery systems
- Compact fluid control in semiconductor equipment
- Hydraulic test bench instrumentation
Installation protocol:
Apply 0.6-0.8 N·m torque during installation. Use thread sealant only on male threads,
avoiding contact with O-ring surfaces. Perform pressure test at 1.25×working pressure
after assembly.
| Property | Property Value |
|---|---|
| sku | BKC0805-02-S |
