Airtac BKC Bulkhead Lock Nut Union BKC0805-03
AirTAC BKC0805-03 Compression Locknut Straight Connector Specifications
- Model: BKC0805-03 (Standard series)
- Type: Male-threaded straight compression fitting
- Thread standard: PT1/8 (BSPP) female thread
- Tube OD compatibility: 8mm (φ8±0.2mm)
- Max working pressure: 1.5 MPa (15 bar)
- Temperature range: -20℃ to 80℃ (continuous operation)
- Body material: C3604 brass with nickel plating
- Seal material: HNBR rubber (-20℃-150℃)
- Alternative seals: FKM available for oil resistance
- Proof pressure: 3.0 MPa (30 bar)
- Vibration resistance: 10-2000Hz, 1.5mm amplitude
- Weight: 23g ±1g (including packaging)
- Dimensions: 25mm(L) × 21mm(W) × 12mm(H)
- Surface roughness: Ra0.8μm (sealing areas)
- Certification: RoHS compliant, REACH SVHC-free
Precision-engineered pneumatic connector featuring triple-locking mechanism (thread+collet+O-ring) for vibration-resistant tubing connections. The electroless nickel plating provides corrosion resistance in humid environments. Designed for zero-leak performance in high-cycle applications.
- Requires 8-10Nm torque during assembly (use backup wrench)
- Ideal for robotic arm pneumatic circuits (6-axis applications)
- Medical device gas delivery systems
- Packaging machine sensor air lines
- Semiconductor fab equipment
- High-frequency valve manifolds
Maintenance tip:
Replace O-rings every 500,000 cycles or 2 years (whichever comes first).
Use thread sealant only on male threads, never on compression surfaces.
| Property | Property Value |
|---|---|
| sku | BKC0805-03 |
