Airtac BKC Bulkhead Lock Nut Union BKC0806-03
$4.77
Regular price
$12.27
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
BKC0806-03
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
AirTAC BKC0806-03 Locknut Straight Connector Specifications
- Model: BKC0806-03
- Type: Swivel nut type straight connector
- Thread standard: Metric (M5×0.8 internal thread)
- Tube compatibility: Ø8mm OD pneumatic tubing
- Material: Nickel-plated brass body
- Seal material: NBR (Nitrile) O-ring
- Max working pressure: 1.5 MPa (15 bar)
- Temperature range: -20℃ to +80℃
- Proof pressure: 2.25 MPa
- Burst pressure: ≥3 MPa
- Weight: 28±2 grams
- Dimensions: 40mm(L) × 24mm(W) × 24mm(H)
- Surface treatment: Electroless nickel plating (5-8μm thickness)
- Vibration resistance: 10-55Hz, 1.5mm amplitude
- Installation torque: 1.2-1.5 N·m recommended
High-pressure resistant connector with 360° rotatable nut for flexible piping alignment. Features triple-sealing structure (thread seal, O-ring seal, and metal-to-metal contact) for leak-free performance in dynamic systems. Compatible with ISO 8434-1/DIN 2353 standards.
Typical Applications:
- Pneumatic cylinder port connections
- Modular FRL (Filter-Regulator-Lubricator) unit assemblies
- Robotic arm pneumatic tooling interfaces
- Compressed air distribution manifolds
- Vacuum system tubing junctions
Installation guide:
Use two wrenches during assembly - one to hold the body (24mm flat surfaces)
and another to tighten the nut. Avoid overtightening beyond 2.0 N·m to prevent
thread deformation. Inspect O-ring for debris before installation.
Media compatibility:
Compressed air, inert gases, and vacuum applications. Not recommended for
hydrocarbons, strong acids, or high-pressure hydraulic fluids.
| Property | Property Value |
|---|---|
| sku | BKC0806-03 |
