Airtac BKC Bulkhead Lock Nut Union BKC0806-03-S
AirTAC BKC0806-03-S Lock Nut Straight Connector Specifications
- Model: BKC0806-03-S
- Type: Lock nut style straight through fitting
- Thread specification: M5×0.8 (male thread)
- Material: Brass with nickel plating (surface hardness ≥HV200)
- Seal material: NBR (Nitrile rubber)
- Operating pressure: 0.05–1.5 MPa
- Temperature range: -20℃ to 80℃
- Tube compatibility: PU/Nylon tubes (OD 8mm, ID 6mm)
- Leakage rate: ≤3.5×10⁻⁴ Pa·m³/s (air under 0.5 MPa)
- Weight: 28g ±1g
- Dimensions: 32mm(L) × 12mm(W) × 12mm(H)
- Surface roughness: Ra ≤1.6μm (sealing surfaces)
- Vibration resistance: 10–2000Hz, 5G acceleration
High-density forged brass connector with 360° rotatable lock nut design enables secure tube connections in confined spaces. Features triple-sealing structure (thread seal + O-ring + tube grip) for leak-proof performance. Nickel plating provides corrosion resistance exceeding 96hrs salt spray test (NSS).
- Pneumatic cylinder port connections
- Modular pneumatic circuit assembly
- Robotic end-effector air supply lines
- Medical equipment gas delivery systems
- Semiconductor cleanroom automation
Installation note:
Insert tube fully until it bottoms out before tightening lock nut.
Recommended torque: 1.2–1.5N·m. For maintenance, replace O-ring
(AS568-006 standard) every 5 years or 10,000 cycles.
| Property | Property Value |
|---|---|
| sku | BKC0806-03-S |
