Airtac BKC Bulkhead Lock Nut Union BKC1065-03
$5.08
Regular price
$12.58
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
BKC1065-03
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
AirTAC BKC1065-03 Lock Nut Straight Connector Technical Details
- Model: BKC1065-03 (Metal Body Series)
- Thread Standard: Metric (M5×0.8 female thread both ends)
- Material:
- Body: Brass (CuZn39Pb3) with nickel plating
- Lock Nut: Reinforced nylon PA66
- Seal: NBR rubber (Fluorine rubber optional)
- Pressure Rating: 0.05-1.5 MPa (7-217 psi)
- Temperature Range:
- Standard Seal: -20℃ to 80℃
- Fluorine Seal: -20℃ to 150℃
- Proof Pressure: 2.25 MPa
- Burst Pressure: ≥3 MPa
- Flow Rate (Cv Value): 0.15
- Weight: 18.5±0.5g
- Dimensions:
- Length: 34.5mm (thread end to end)
- Body Diameter: Φ12mm
- Hex Size: 12mm wrench compatible
- Vibration Resistance: 10-55Hz, 1.5mm amplitude
- Certifications: RoHS compliant, REACH SVHC free
High-density machining connector with anti-vibration lock nut design, featuring dual-layer sealing structure (radial O-ring + axial face seal). The 45° inverted tooth locking mechanism prevents tube slippage under pulsating pressure. Compatible with PU/Nylon tubes (OD 4mm or 6mm).
Industrial Applications:
- Pneumatic cylinder supply lines in automotive assembly robots
- Coolant line connections for CNC spindle motors
- Vacuum system plumbing in semiconductor handling equipment
- Modular pneumatic circuit prototyping
- High-cycle packaging machine air networks
Installation protocol:
Hand-tighten until resistance is felt, then apply 1/4 turn with wrench.
Maximum torque 1.2N·m. Avoid installing near chemicals causing nylon
degradation (e.g., strong acids/phenols). Perform pressure test at
1.25×system pressure after installation.
| Property | Property Value |
|---|---|
| sku | BKC1065-03 |
