Airtac BKC Bulkhead Lock Nut Union BKC1065-03-S
AirTAC BKC1065-03-S Locknut Straight Connector Specifications
- Model: BKC1065-03-S
- Type: Reusable locknut straight connector
- Material: Brass (nickel-plated body)
- Seal material: NBR/FKM (optional)
- Thread specification: G1/8 (ISO228-1 standard)
- Max working pressure: 1.5 MPa (15 bar)
- Temperature range: -20℃ to 80℃ (NBR) / -20℃ to 120℃ (FKM)
- Tube OD compatibility: 6mm (4mm ID)
- Torque requirement: 1.2-1.5 N·m (hand-tighten + 1/4 turn)
- Surface treatment: Electrolytic nickel plating (≥5μm)
- Weight: 28g ±0.5g
- Dimensions: 40mm(L) × 18mm(W) × 18mm(H)
- Vibration resistance: ≤10Hz/1.5mm amplitude
High-pressure resistant pneumatic connector featuring double-sealing structure with primary O-ring and secondary metal-to-metal seal. The knurled locknut design enables tool-free installation while preventing accidental disconnection. Compatible with air, water, and light hydraulic fluids.
- Pneumatic cylinder port connections
- CNC machine tool coolant lines
- Compressed air distribution manifolds
- Robotic arm pneumatic gripper systems
- Semiconductor equipment gas delivery
Installation note:
Ensure tube end is cut square and deburred before insertion. For FKM seals,
apply silicone-free lubricant when operating below -10℃. Maximum 5 reuses recommended.
| Property | Property Value |
|---|---|
| sku | BKC1065-03-S |
