Airtac BKC Bulkhead Lock Nut Union BKC1065-04
AirTAC BKC1065-04 Locknut Straight Through Connector Specifications
- Model: BKC1065-04
- Series: BKC (Locknut Straight Connector Series)
- Thread type: G1/4 (BSPP)
- Material: Stainless steel (SUS303)
- Seal material: NBR (Nitrile Rubber)
- Operating pressure: 0.5-1.6 MPa
- Temperature range: -20℃ to 80℃
- Surface treatment: Natural color anodizing
- Proof pressure: 2.4 MPa
- Burst pressure: ≥4.8 MPa
- Weight: 62g ±2g
- Dimensions: 32mm(L) × 12mm(Ø body) × 17mm(Ø hex)
- Thread engagement depth: 9mm
- Torque specification: 14-16 N·m
- Fluid compatibility: Air, inert gases, water (non-corrosive media)
A high-pressure resistant straight connector with integrated locknut design, featuring SUS303 stainless steel construction for enhanced corrosion resistance in humid environments. The tapered thread design with NBR sealing ensures leak-free connections even under vibration-intensive conditions. Pre-lubricated for smoother assembly.
- Pneumatic tool air supply lines
- CNC machine coolant distribution systems
- High-cycle automation equipment manifolds
- Semiconductor factory vacuum line connections
- Hydraulic test bench plumbing
- Use two wrenches - one to hold the body and another to tighten the locknut
- Apply PTFE tape or liquid sealant to male threads (do NOT over-tighten)
- Align tubing axis within ±3° to prevent lateral stress
- Pressure test at 1.25× working pressure after installation
Caution: Avoid using with ethylene glycol-based fluids or chlorinated solvents.
Maximum 500 connection/disconnection cycles recommended for seal integrity.
| Property | Property Value |
|---|---|
| sku | BKC1065-04 |
