Airtac BKC Bulkhead Lock Nut Union BKC1065-04-S
AirTAC BKC1065-04-S Lock Nut Straight Connector Specifications
- Model: BKC1065-04-S
- Type: Lock nut style straight fitting (male thread to tube)
- Material: Stainless steel (SUS303) body with nickel-plated brass lock nut
- Thread specification: 1/4" BSPP (G1/4)
- Tube O.D. compatibility: 6mm (4mm I.D. tubing)
- Max working pressure: 1.5 MPa (15 bar)
- Temperature range: -20℃ to 100℃ (static) / -5℃ to 80℃ (dynamic)
- Seal material: NBR (Nitrile) rubber
- Surface treatment: Electropolished internals
- Weight: 48g ±2g
- Dimensions: 32mm(L) × 18mm(W) × 18mm(H)
- Vibration resistance: ≤20 m/s² (ISO 10816-3)
- Certification: RoHS compliant
A corrosion-resistant, high-pressure pneumatic connector featuring dual sealing surfaces and anti-vibration lock nut design. The 360° rotatable fitting allows flexible tubing alignment while maintaining leak-proof performance. Includes built-in grip ridges for tool-free hand tightening in confined spaces.
- High-cycle pneumatic cylinder installations
- CNC machine tool air supply lines
- Semiconductor manufacturing equipment
- Hydraulic test bench connections
- Food processing pneumatic systems (non-contact areas)
Installation note:
Apply 2-3 drops of pneumatic sealant on threads before assembly.
Tighten lock nut to 12-15 N·m torque using 17mm wrench.
Maximum 120° tube bend radius recommended.
Compatibility alert:
Not suitable for PTFE tubing or fluids containing H2S.
Always use tube inserts with soft pneumatic tubing.
| Property | Property Value |
|---|---|
| sku | BKC1065-04-S |
