Airtac BPM Full Metal Panel Mount Straight Through Fitting BPM10
AirTAC BPM10 All-Metal Bulkhead Straight Through Fitting Specifications
- Model: BPM10
- Material: Stainless steel 304/316 (body), Brass optional
- Thread standard: Metric M10×1.0
- Port configuration: Dual female threads
- Max working pressure: 1.5 MPa (217 psi)
- Burst pressure: ≥4.5 MPa
- Temperature range: -20℃ to 150℃
- Seal material: HNBR (standard), FKM available for high temp
- Surface treatment: Passivation (stainless steel), Electroless nickel plating (brass)
- Installation thickness: 1-5mm panel compatibility
- Weight: 28g ±2g
- Dimensions: 42mm(Length) × 24mm(Width) × 16mm(Height)
- Certifications: RoHS compliant, REACH compliant
Heavy-duty bulkhead connector featuring full-metal construction for enhanced durability in high-vibration environments. The through-panel design enables secure fluid path transition between compartments while maintaining pressure integrity. Precision CNC machining ensures leak-free performance even under thermal cycling conditions.
- Hydraulic power unit panel mounting
- CNC machine lubrication systems
- Semiconductor manufacturing equipment
- High-pressure washdown systems
- Mobile hydraulic machinery
- Thermal oil circulation systems
Installation guidance:
Use two backup wrenches during assembly to prevent body distortion.
Apply thread sealant only on male threads (tapered ends).
Maximum tightening torque: 15 N·m for stainless steel version, 12 N·m for brass.
| Property | Property Value |
|---|---|
| sku | BPM10 |
